MPN:
TQXGE-700SAP
TooQ TQXGE-700SAP power supply unit 700 W 20+4 pin ATX ATX Black
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- Wattage
- 700 W
- Efficiency rating
- 80 PLUS
- Depth
- 150 mm
- Width
- 160 mm
- Height
- 86 mm
- Manual included
- Y
- Purpose
- PC
- Efficiency
- 80
- ATX version
- 2.31
1 / 9
Shopping actions
Overview
The TooQ TQXGE-700SAP power supply unit 700 W 20+4 pin ATX ATX Black features 700 W output, 80 PLUS 80 PLUS efficiency and a 140 mm fan. Full verified specifications are listed below.
Technical Specifications
Physical
4 SPECS
Depth
150 mm
Width
160 mm
Height
86 mm
Colour
Black
Power
2 SPECS
Wattage
700 W
Efficiency rating
80 PLUS
Graphics
1 SPEC
Illumination
Yes
Logistics & Packaging
4 SPECS
Package depth
280 mm
Package width
105 mm
Package height
235 mm
Package weight
2930 g
Cooling
2 SPECS
Fan size
140
Number of fans
1
General
34 SPECS
Manual included
Yes
Purpose
PC
Efficiency
80
ATX version
2.31
EPS version
2.92
Noise level
17
Cabling type
Non-Modular
Certifications
CE / UL / FCC / BSMI / GOST / CCC / KCC
Included cables
AC
AC input voltage
100 - 264
AC input frequency
47 - 63
Illumination colour
Blue
Combined power (+5V)
150
Combined power (+12V)
600
Combined power (-12V)
6
Combined power (+3.3V)
150
Combined power (+5Vsb)
10
Compliance certificates
RoHS
Max output current (+5V)
20
Max output current (-12V)
0.5
Power protection features
Over current,Over power,Over voltage,Overheating,Short circuit,Under voltage
Max output current (+12V1)
28
Max output current (+12V2)
28
Max output current (+3.3V)
20
Max output current (+5Vsb)
2
Floppy disk drive connector
Yes
Motherboard power connector
20+4 pin ATX
Floppy drive power connector
1
CPU power connector (4+4 pin)
Yes
Number of SATA power connectors
6
Power Factor Correction (PFC) type
Active
Power supply unit (PSU) form factor
ATX
PCI Express power connectors (6+2 pin)
2
Peripheral (Molex) power connectors (4-pin)
3
