Shuttle logo MPN: DS20U3V2

Shuttle XPC slim Barebone DS20U3V2, i3-10110U, 2x LAN (1xGbit, 1x 2.5Gbit),1xCOM,1xHDMI,1xDP, fanless, 24/7 permanent operation

Released: Not on record
Price not yet available US · Amazon.com

We track this product’s Amazon US price daily — it appears here as soon as it’s listed.

Depth
200 mm
Wi-Fi
N
Width
165 mm
Height
39.5 mm
Weight
1500 g
Non-ECC
Y
64-bit support
Y
BIOS type
UEFI AMI
DC-in jack
Y
View 99 specifications
1 / 8
Shopping actions
Check price on Amazon

Overview

Fanless Slim PC with a Comet-Lake-U processor in industrial design
The DS20UV2-series is a fanless slim PC with a robust 1.3-litre metal chassis and exceptional connectivity. It supports two digital video outputs for UHD/4K displays and one tradi-tional D-Sub/VGA connector. The built-in Intel "Comet-Lake-U" processor provides ample performance for playback of 2160p/60 videos. Installation of components goes straight forward, as there is plenty of interior space for two memory modules, one 2.5" drive and an M.2-2280 SSD card. Optionally, an LTE module can be fitted in the 2,5" bay using the WWN03 accessory. Thanks to its passive cooling, the system is virtually maintenance-free and is approved for 24/7 nonstop operation. It is big on performance, yet extremely energy-efficient. The Shuttle XPC slim Barebone DS20UV2 series is an ideal platform for professional applications such as digital signage, POS, Kiosk, Thin Client, Office PC and Multimedia.

Technical Specifications

Processor

10 SPECS
Cache
4 MB
Cores
2
Model
i3-10110U
Processor line
Intel Core i3
Threads
4
Clock speed
2.1 GHz
Process node
14 nm
CPU brand
Intel
Boost clock
4.1 GHz
TDP
15 W

Memory

3 SPECS
Voltage
1.2 V
Memory slots
2
Max memory
64 GB

Cooling

1 SPEC
Cooling type
Passive

Physical

7 SPECS
Depth
200 mm
Width
165 mm
Height
39.5 mm
Weight
1500 g
Product type
Mini PC (<= 3L) barebone
Colour
Black
Customs (HS) code
84733080

Ports & Connectivity

4 SPECS
HDMI ports
1
DisplayPorts quantity
1
USB 2.0 ports
4
Ethernet ports
2

Logistics & Packaging

2 SPECS
Package weight
2200 g
Country of origin
China

General

72 SPECS
Wi-Fi
No
Non-ECC
Yes
64-bit support
Yes
BIOS type
UEFI AMI
DC-in jack
Yes
Idle power states
Yes
Chassis type
1.3L sized PC
Ethernet LAN
Yes
HDMI version
2.0a
Intel TSX-NI
No
Power supply
65
Microphone input
Yes
On/off switch
Yes
VESA mounting
Yes
LAN controller
Intel I211,Intel I219
LED indicators
HDD,Power
Security lock slot
Yes
Memory channels
Dual-channel
AC input voltage
100 - 240
Drivers included
Yes
Headphone outputs
1
Memory slots type
SO-DIMM
Power supply type
External AC adapter
Quick start guide
Yes
AC input frequency
50 - 60
Built-in processor
Yes
AC adapter included
Yes
Built-in speaker(s)
No
DisplayPort version
1.2
Execute Disable (NX)
Yes
Chipset
Intel SoC
Power cord included
Yes
Cable lock slot type
Kensington
Graphics card family
Intel
Generation
Intel Core i3-10xxx
Serial ports
1
Card reader
Yes
Integrated graphics
Yes
Supported memory types
DDR4-SDRAM
CPU configuration (max)
1
Compatible memory cards
SD,SDHC,SDXC
Number of M.2 (M) slots
1
Storage drive interface
PCI Express,Serial ATA III
Intel Flex Memory Access
Yes
AC adapter output current
3.42 A
AC adapter output voltage
19 V
PCI Express slots version
3.0
Long-term availability
No
Operating system
No
VGA ports
1
Operating temperature
0 - 40
Intel Clear Video Technology
Yes
Number of power supply units
1
Integrated GPU model
Intel UHD Graphics
Storage drive sizes supported
2.5,M.2
Supported memory clock speeds
2666,3200
Supported storage drive types
HDD & SSD
Trusted Platform Module (TPM)
Yes
Number of processors supported
1
Linux distributions supported
Yes
Operating humidity
10 - 90
Trusted Execution (TXT)
No
Number of storage drives supported
2
SpeedStep power scaling
Yes
Windows versions supported
Windows 10,Windows 11
Trusted Platform Module (TPM) version
2.0
Virtualization (VT-x)
Yes
Intel Stable Image Platform Program (SIPP)
No
Intel VT-x with Extended Page Tables (EPT)
Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
Directed I/O virtualization (VT-d)
Yes
