MPN:
DS57U5
Shuttle DS57U5 PC/workstation barebone Nettop Black i5-5200U BGA 1168 2.2 GHz
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- ECC support
- N
- Depth
- 39.5 mm
- Wi-Fi
- Y
- Width
- 165 mm
- Height
- 200 mm
- Safety
- CB, BSMI, ETL, CCC
- Weight
- 1430 g
- 64-bit support
- Y
- BIOS type
- UEFI AMI
1 / 10
Shopping actions
Overview
The Shuttle DS57U5 PC/workstation barebone Nettop Black i5-5200U BGA 1168 2.2 GHz features Intel Core i5 processor, 2 cores, up to 2.7 GHz boost and Passive cooling. Full verified specifications are listed below.
Technical Specifications
Processor
10 SPECS
Cores
2
Model
i5-5200U
Processor line
Intel Core i5
Socket
BGA 1168
Threads
4
Clock speed
2.2 GHz
Process node
14 nm
CPU brand
Intel
Boost clock
2.7 GHz
TDP
15 W
Memory
3 SPECS
ECC support
No
Memory slots
2
Max memory
16 GB
Logistics & Packaging
1 SPEC
Package weight
2130 g
Physical
6 SPECS
Depth
39.5 mm
Width
165 mm
Height
200 mm
Weight
1430 g
Product type
Mini PC (<= 3L) barebone
Colour
Black
Ports & Connectivity
4 SPECS
HDMI ports
1
DisplayPorts quantity
1
USB 2.0 ports
4
Ethernet ports
2
Cooling
1 SPEC
Cooling type
Passive
General
80 SPECS
Wi-Fi
Yes
Safety
CB, BSMI, ETL, CCC
64-bit support
Yes
BIOS type
UEFI AMI
DC-in jack
Yes
Idle power states
Yes
Audio system
HD
Chassis type
Nettop
Ethernet LAN
Yes
HDMI version
1.4a
Power supply
65
Certifications
FCC, CE, BSMI, C-Tick
Microphone input
Yes
LED indicators
HDD,Power
Security lock slot
Yes
Memory channels
Dual-channel
AC input voltage
100 - 240
Housing material
Steel
Intel® OS Guard
Yes
Processor series
Intel Core i5-5200 Mobile series
Headphone outputs
1
Memory slots type
SO-DIMM
Power supply type
External AC adapter
Quick start guide
Yes
AC input frequency
50 - 60
Built-in processor
Yes
Intel® Insider™
Yes
Intel® Secure Key
Yes
Codename
Broadwell
AC adapter included
Yes
Execute Disable (NX)
Yes
Power cord included
Yes
Cable lock slot type
Kensington
Graphics card family
Intel
Intel FDI Technology
Yes
Generation
Intel Core i5-5xxx
Serial ports
2
Card reader
Yes
Integrated graphics
Yes
Supported memory types
DDR3L-SDRAM
CPU configuration (max)
1
Compatible memory cards
SD,SDHC,SDXC
Storage drive interface
Serial ATA III
Intel Fast Memory Access
Yes
Intel Flex Memory Access
Yes
Panel mounting interface
100 x 75
AC adapter output current
3.42 A
AC adapter output voltage
19 V
PCI Express slots version
2.0
Long-term availability
No
Operating system
No
PCI Express configurations
4x1,2x4
VGA ports
0
Operating temperature
0 - 40
Compatible OS
Windows 8, Windows 7, Linux
Intel Clear Video Technology
Yes
Number of power supply units
1
Integrated GPU model
Intel HD Graphics 5500
Storage drive sizes supported
2.5
Supported memory clock speeds
1333,1600
Supported storage drive types
HDD & SSD
Intel® InTru™ 3D Technology
Yes
Intel® Turbo Boost Technology
2.0
Number of processors supported
1
Thermal monitoring
Yes
Intel® Smart Response Technology
Yes
Operating humidity
10 - 90
Number of storage drives supported
1
SpeedStep power scaling
Yes
Intel® Quick Sync Video Technology
Yes
Virtualization (VT-x)
Yes
Intel® Wireless Display (Intel® WiDi)
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
Intel® AES New Instructions (Intel® AES-NI)
Yes
Intel® Small Business Advantage (Intel® SBA)
Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
Intel® Clear Video HD Technology (Intel® CVT HD)
Yes
Intel® Identity Protection Technology (Intel® IPT)
Yes
Directed I/O virtualization (VT-d)
Yes
Intel® Hyper Threading Technology (Intel® HT Technology)
Yes
