MPN:
GB-BSI3HA-6100
GIGABYTE GB-BSI3HA-6100 PC/workstation barebone 0.6L sized PC Black i3-6100U BGA 1356 2.3 GHz
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- ECC support
- N
- Depth
- 112.6 mm
- Wi-Fi
- Y
- Width
- 119.4 mm
- Height
- 46.8 mm
- 64-bit support
- Y
- L3 cache
- 3 MB
- Bluetooth
- Y
- DC-in jack
- Y
1 / 5
Shopping actions
Overview
The GIGABYTE GB-BSI3HA-6100 PC/workstation barebone 0.6L sized PC Black i3-6100U BGA 1356 2.3 GHz features Intel Core i3 processor, 2 cores and Passive cooling. Full verified specifications are listed below.
Technical Specifications
Processor
9 SPECS
Cores
2
Model
i3-6100U
Processor line
Intel Core i3
Socket
BGA 1356
Threads
4
Clock speed
2.3 GHz
Process node
14 nm
CPU brand
Intel
TDP
15 W
Ports & Connectivity
3 SPECS
HDMI ports
1
USB 2.0 ports
0
Ethernet ports
1
Physical
5 SPECS
Depth
112.6 mm
Width
119.4 mm
Height
46.8 mm
Product type
Mini PC (<= 3L) barebone
Colour
Black
Memory
3 SPECS
ECC support
No
Memory slots
2
Max memory
32 GB
Cooling
1 SPEC
Cooling type
Passive
General
82 SPECS
Wi-Fi
Yes
64-bit support
Yes
L3 cache
3 MB
Bluetooth
Yes
DC-in jack
Yes
Idle power states
Yes
Audio system
Realtek ALC255
Chassis type
0.6L sized PC
Ethernet LAN
Yes
HDMI version
1.4a
Intel TSX-NI
No
Conflict-Free
Yes
VESA mounting
Yes
LAN controller
Intel I219LM
Security lock slot
Yes
Memory channels
Dual-channel
AC input voltage
100 - 240
Housing material
Aluminium
Intel® OS Guard
Yes
Intel ARK ID
88180
Processor series
Intel Core i3-6100 series
Bluetooth version
4.2
Headphone outputs
1
Memory slots type
SO-DIMM
Power supply type
External AC adapter
Built-in processor
Yes
Intel® Insider™
Yes
Intel® Secure Key
Yes
Codename
Skylake
DisplayPort version
1.2
Execute Disable (NX)
Yes
Intel® Smart Cache
Yes
Cable lock slot type
Kensington
Graphics card family
Intel
PCI Express x1 slots
2
Generation
Intel Core i3-6xxx
Memory bandwidth (max)
34.1 GB/s
Integrated graphics
Yes
Supported memory types
DDR4-SDRAM
CPU configuration (max)
1
Storage drive interface
Serial ATA III
Combo headphone/mic port
Yes
Intel Flex Memory Access
Yes
Panel mounting interface
75 x 75,100 x 100
AC adapter output current
3.42 A
AC adapter output voltage
19 V
PCI Express slots version
3.0
Storage temperature
-20 - 60
Long-term availability
Yes
Mini DisplayPorts quantity
1
PCI Express configurations
1x4,4x1
VGA ports
0
Operating temperature
0 - 35
Intel Clear Video Technology
Yes
Max graphics memory
32768 GB
Number of displays supported
3
Integrated GPU model
Intel HD Graphics 520
Storage drive sizes supported
2.5
Supported memory clock speeds
2133
Supported storage drive types
HDD & SSD
Intel® InTru™ 3D Technology
Yes
Intel® Turbo Boost Technology
No
Thermal monitoring
Yes
Intel® Smart Response Technology
Yes
Trusted Execution (TXT)
No
SpeedStep power scaling
Yes
Intel® Quick Sync Video Technology
Yes
Windows versions supported
Windows 10 Home,Windows 10 Pro,Windows 7 Home Basic,Windows 7 Home Premium,Windows 7 Professional,Windows 8.1,Windows 8.1 Pro
Virtualization (VT-x)
Yes
Intel® Wireless Display (Intel® WiDi)
Yes
Intel® My WiFi Technology (Intel® MWT)
Yes
Intel Stable Image Platform Program (SIPP)
No
Intel VT-x with Extended Page Tables (EPT)
Yes
Intel® AES New Instructions (Intel® AES-NI)
Yes
Intel® Small Business Advantage (Intel® SBA)
Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
1
Intel® Clear Video HD Technology (Intel® CVT HD)
Yes
Intel® Identity Protection Technology (Intel® IPT)
Yes
Directed I/O virtualization (VT-d)
Yes
Intel® Hyper Threading Technology (Intel® HT Technology)
Yes
Market Value History
Price history not started yet
Daily price tracking begins as soon as this product is listed on Amazon US — the trend chart will appear here automatically.
Sources
Product lifecycle
In production
Still listed as on-market by the manufacturer — actively sold and supported.
Lifecycle status is derived from catalog data and is indicative, not a manufacturer support guarantee.
