MPN:
GB-BACE-3000
GIGABYTE GB-BACE-3000 PC/workstation barebone Nettop Black N3000 BGA 1170 1.04 GHz
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- Depth
- 1076 mm
- Wi-Fi
- Y
- Width
- 56.1 mm
- Height
- 114.4 mm
- DVI port
- Y
- Drive form factor
- 2.5
- 64-bit support
- Y
- Bluetooth
- Y
- DC-in jack
- Y
1 / 5
Shopping actions
Overview
The GIGABYTE GB-BACE-3000 PC/workstation barebone Nettop Black N3000 BGA 1170 1.04 GHz features Intel Celeron processor, 2 cores and up to 2.08 GHz boost. Full verified specifications are listed below.
Technical Specifications
Processor
10 SPECS
Cores
2
Model
N3000
Processor line
Intel Celeron
Socket
BGA 1170
Threads
2
Clock speed
1.04 GHz
Process node
14 nm
CPU brand
Intel
Boost clock
2.08 GHz
TDP
4 W
Ports & Connectivity
3 SPECS
HDMI ports
1
USB 2.0 ports
0
Ethernet ports
1
Physical
5 SPECS
Depth
1076 mm
Width
56.1 mm
Height
114.4 mm
Product type
Mini PC (<= 3L)
Colour
Black
Memory
3 SPECS
Voltage
1.35 V
Memory slots
1
Max memory
8 GB
General
84 SPECS
Wi-Fi
Yes
DVI port
Yes
Drive form factor
2.5
64-bit support
Yes
Bluetooth
Yes
DC-in jack
Yes
Idle power states
Yes
Audio system
Realtek ALC255
Chassis type
Nettop
Ethernet LAN
Yes
Microphone input
Yes
VESA mounting
Yes
Mouse included
No
Security lock slot
Yes
Wi-Fi standard
802.11b,802.11g,Wi-Fi 4 (802.11n)
AC input voltage
100 - 240
Display included
No
Intel® OS Guard
No
Processor series
Intel Celeron N3000 series
Bluetooth version
4.0
Headphone outputs
1
Keyboard included
No
Memory slots type
SO-DIMM
Power supply type
External AC adapter
AC input frequency
50 - 60
Built-in processor
Yes
Intel® Insider™
No
Intel® Secure Key
Yes
Codename
Braswell
Execute Disable (NX)
Yes
Intel® Smart Cache
No
Cable lock slot type
Kensington
Intel FDI Technology
No
Card reader
Yes
Integrated graphics
Yes
Supported memory types
DDR3L-SDRAM
CPU configuration (max)
1
Storage drive interface
Serial ATA III
Intel Fast Memory Access
No
Intel Flex Memory Access
No
AC adapter output current
2.1 A
AC adapter output voltage
19 V
PCI Express slots version
2.0
Storage temperature
-20 - 60
Long-term availability
No
Operating system
No
PCI Express configurations
1x4,4x1
VGA ports
1
Operating temperature
0 - 35
Intel Clear Video Technology
Yes
Intel Demand Based Switching
No
Number of SATA III connectors
2
Storage drive sizes supported
2.5
Supported memory clock speeds
1066,1600
Supported storage drive types
HDD
Intel Rapid Storage Technology
No
Intel Smart Connect Technology
No
Intel® InTru™ 3D Technology
No
Intel® Turbo Boost Technology
No
Number of processors installed
1
Number of processors supported
1
Thermal monitoring
Yes
Intel® Smart Response Technology
No
Trusted Execution (TXT)
No
Number of storage drives installed
0
Number of storage drives supported
1
SpeedStep power scaling
Yes
Intel® Quick Sync Video Technology
Yes
Intel Dual Display Capable Technology
No
Virtualization (VT-x)
Yes
Intel® Wireless Display (Intel® WiDi)
Yes
Intel® My WiFi Technology (Intel® MWT)
No
Intel Stable Image Platform Program (SIPP)
No
Intel VT-x with Extended Page Tables (EPT)
Yes
Intel® Anti-Theft Technology (Intel® AT)
No
Intel® AES New Instructions (Intel® AES-NI)
Yes
Intel® Small Business Advantage (Intel® SBA)
No
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
0
Intel® High Definition Audio (Intel® HD Audio)
Yes
Intel® Clear Video HD Technology (Intel® CVT HD)
Yes
Intel® Identity Protection Technology (Intel® IPT)
Yes
Directed I/O virtualization (VT-d)
No
Intel® Hyper Threading Technology (Intel® HT Technology)
No
