be quiet! logo MPN: BP025EU

be quiet! Pure Power 13 M | 650W power supply unit 20+4 pin ATX ATX Black

Released: Not on record
$254.56 from US · Amazon.com Updated 2 weeks ago Last updated Sep 3, 2026 03:14 UTC

Ratings & price sourced from Amazon.com (United States).

Wattage
650 W
Efficiency rating
80 PLUS Gold
Depth
160 mm
Width
150 mm
Height
86 mm
Weight
2320 g
Purpose
PC
Fan speed
0 - 1800
Hold time
22.5
View 69 specifications
1 / 6
Shopping actions
Check price on Amazon

Overview

Exceptional quiet, superior features
Pure Power 13 M 650W is an ATX 3.1 compliant and PCIe 5.1 compatible power supply with semi-passive cooling. It offers peerless dependability with best-in-class features. Having both a PCIe 5.1 cable and PCIe 6+2 cables in the scope of delivery, this PSU offers outstanding compatibility with current-gen and next-gen graphics cards. Pure Power 13 M 650W offers the best combination of features with outstanding compatibility.

Technical Specifications

Physical

5 SPECS
Depth
160 mm
Width
150 mm
Height
86 mm
Weight
2320 g
Colour
Black

Cooling

3 SPECS
Cooling type
Active
Fan size
120
Number of fans
1

Logistics & Packaging

5 SPECS
Package depth
320 mm
Package width
210 mm
Package height
133 mm
Package weight
3100 g
Shipping (inner) case gross weight
20900

Power

2 SPECS
Wattage
650 W
Efficiency rating
80 PLUS Gold

Graphics

1 SPEC
Illumination
No

General

53 SPECS
Purpose
PC
Fan speed
0 - 1800
Hold time
22.5
Efficiency
92.8
Peak power
720
ATX version
3.1
EPS version
2.92
Noise level
30.2
Cabling type
Fully-Modular
Power factor
0.98
On/off switch
Yes
Included cables
AC,CPU,PCIe,Peripheral (Molex),SATA
Screws included
Yes
AC input voltage
100 - 240
AC input frequency
50/60
Bearing type
Rifle
Cable ties included
Yes
Combined power (+5V)
120
Combined power (+12V)
650
Combined power (-12V)
3.6
PCI Express connector
Yes
CPU power cable length
650
Combined power (+3.3V)
120
Combined power (+5Vsb)
15
Number of +12V rail(s)
1
Compliance certificates
BSMI,CB,CCC,CE,Federal Communications Commission (FCC),IRAM,RCM,RoHS,TÜV mark,UKCA,WEEE,cTUVus
SATA power cable length
500,650,800
CPU P4 connector (4-pin)
3
Max output current (+5V)
20
Max output current (-12V)
0.3
Power protection features
Over current,Over power,Over voltage,Overheating,Short circuit,Surge & inrush protection (SIP),Under voltage
Max output current (+12V1)
54.1
Max output current (+3.3V)
20
Max output current (+5Vsb)
3
Motherboard power connector
20+4 pin ATX
Operating temperature
0 - 40
Shipping (inner) case width
325
Eco certifications
ENERGY STAR,ErP
Shipping (inner) case height
233
Shipping (inner) case length
580
CPU power connector (4+4 pin)
Yes
Maximum input current (@110V)
10
Maximum input current (@220V)
5
Motherboard power cable length
550
Number of SATA power connectors
5
MTBF
100000 h
Power Factor Correction (PFC) type
Active
Products per shipping (inner) case
6
Power supply unit (PSU) form factor
ATX
PCI Express power connectors (12-pin)
1
Peripheral (Molex) power cable length
800,950
PCI Express power connectors (6+2 pin)
2
Peripheral (Molex) power connectors (4-pin)
2
