MPN:
90MB0F50-M0EAY5
ASUS H87M-E Intel® H87 LGA 1150 (Socket H3) micro ATX
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- Depth
- 193 mm
- Width
- 244 mm
- BIOS type
- UEFI AMI
- Audio chip
- Realtek ALC887
- RAID levels
- 0,1,5,10
- Ethernet LAN
- Y
- Intended use
- PC
- Microphone input
- Y
- LAN controller
- Realtek 8111G
1 / 3
Shopping actions
Overview
The ASUS H87M-E Intel® H87 LGA 1150 (Socket H3) micro ATX (Depth: 193 mm). Full verified specifications are listed below.
Technical Specifications
Ports & Connectivity
5 SPECS
HDMI ports
1
PS/2 ports
2
DVI-D ports quantity
1
USB 2.0 ports
2
Ethernet ports
1
Memory
2 SPECS
Memory slots
4
Max memory
32 GB
Power
1 SPEC
Power source
ATX
Processor
3 SPECS
Bundled software
ASUS Utilities
ASUS EZ Update
Anti-virus software (OEM version)
Socket
LGA 1150 (Socket H3)
CPU brand
Intel
Physical
3 SPECS
Depth
193 mm
Width
244 mm
Form factor
Micro ATX
Graphics
1 SPEC
Max resolution
4096 x 2160
General
51 SPECS
BIOS type
UEFI AMI
Audio chip
Realtek ALC887
RAID levels
0,1,5,10
Ethernet LAN
Yes
Intended use
PC
Microphone input
Yes
LAN controller
Realtek 8111G
Included cables
SATA
Memory channels
Dual-channel
Bus speed
6 GT/s
BIOS memory size
64 MB
Drivers included
Yes
CPU fan connector
Yes
Clear CMOS jumper
Yes
Headphone outputs
1
Memory slots type
DIMM
Unbuffered memory
Yes
ECC сompatibility
non-ECC
USB 2.0 connectors
3
Chipset
Intel H87
Number of DIMM slots
4
S/PDIF out connector
Yes
eSATA ports quantity
0
mSATA ports quantity
0
Audio channels
7.1
Integrated graphics
Yes
Supported memory types
DDR3-SDRAM
Ethernet interface type
Gigabit Ethernet
Number of COM connectors
1
FireWire ports
0
Motherboard chipset family
Intel
PCI Express slots quantity
4
VGA ports
1
Chassis intrusion connector
Yes
Compatible processor series
Intel Celeron,Intel Pentium
EPS power connector (8-pin)
Yes
ATX Power connector (24-pin)
Yes
Max graphics memory
1024 GB
Number of SATA II connectors
0
Number of displays supported
3
Number of SATA III connectors
6
Supported memory clock speeds
1066,1333,1600
Number of processors supported
1
PCI Express x1 (Gen 2.x) slots
3
PCI Express x16 (Gen 3.x) slots
1
Number of Parallel ATA connectors
0
Supported storage drive interfaces
SATA III
Windows versions supported
Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64
USB 3.2 Gen 1 (3.1 Gen 1) connectors
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
Intel® Clear Video HD Technology (Intel® CVT HD)
Yes
