MPN:
90MB0N10-M0ECY0
ASUS H170I-PLUS D3 Intel® H170 mini ITX
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- Depth
- 170 mm
- Wi-Fi
- Y
- Width
- 170 mm
- BIOS type
- UEFI AMI
- Bluetooth
- Y
- ACPI version
- 5.0
- Ethernet LAN
- Y
- Intended use
- PC
- TPM connector
- Y
1 / 6
Shopping actions
Overview
The ASUS H170I-PLUS D3 Intel® H170 mini ITX (Depth: 170 mm). Full verified specifications are listed below.
Technical Specifications
Ports & Connectivity
6 SPECS
HDMI ports
1
PS/2 ports
1
DVI-D ports quantity
1
DisplayPorts quantity
1
USB 2.0 ports
0
Ethernet ports
1
Processor
1 SPEC
CPU brand
Intel
Power
1 SPEC
Power source
ATX
Physical
3 SPECS
Depth
170 mm
Width
170 mm
Form factor
Mini ITX
Memory
2 SPECS
Memory slots
2
Max memory
32 GB
Storage
1 SPEC
SATA ports
5
General
44 SPECS
Wi-Fi
Yes
BIOS type
UEFI AMI
Bluetooth
Yes
ACPI version
5.0
Ethernet LAN
Yes
Intended use
PC
TPM connector
Yes
LAN controller
Intel I219-V
S/PDIF out port
Yes
Wi-Fi standard
802.11a,Wi-Fi 5 (802.11ac),802.11b,802.11g,Wi-Fi 4 (802.11n)
BIOS memory size
16 MB
Bluetooth version
4.0
CPU fan connector
Yes
Clear CMOS jumper
Yes
Memory slots type
DIMM
Unbuffered memory
Yes
ECC сompatibility
non-ECC
USB 2.0 connectors
2
Chipset
Intel H170
eSATA ports quantity
0
Audio channels
7.1
Supported memory types
DDR3-SDRAM
Ethernet interface type
Gigabit Ethernet
Number of M.2 (M) slots
1
Number of COM connectors
1
FireWire ports
0
Motherboard chipset family
Intel
VGA ports
1
Compatible processor series
Intel Celeron,Intel Pentium
Front panel audio connector
Yes
ATX Power connector (24-pin)
Yes
Number of SATA II connectors
0
Number of SATA III connectors
4
Supported memory clock speeds
1333,1600,1866
Number of EATX power connectors
1
PCI Express x16 (Gen 3.x) slots
1
Number of chassis fan connectors
2
Number of Parallel ATA connectors
0
Number of SATA Express connectors
1
Intel Extreme Memory Profile (XMP)
Yes
Supported storage drive interfaces
M.2,SATA III
USB 3.2 Gen 1 (3.1 Gen 1) connectors
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
6
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
0
Market Value History
Price history not started yet
Daily price tracking begins as soon as this product is listed on Amazon US — the trend chart will appear here automatically.
Sources
Product lifecycle
In production
Still listed as on-market by the manufacturer — actively sold and supported.
Lifecycle status is derived from catalog data and is indicative, not a manufacturer support guarantee.
