MPN:
90-MIBGL0-G0EAY00Z
ASUS F1A75-M LE AMD Hudson D3 Socket FM1 micro ATX
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- Depth
- 229 mm
- Width
- 244 mm
- BIOS type
- AMI
- PCI slots
- Y
- Audio chip
- Realtek ALC887
- RAID levels
- 0,1,10,JBOD
- ACPI version
- 2.0a
- Intended use
- PC
- Graphics card
- Radeon HD 6000
1 / 4
Shopping actions
Overview
The ASUS F1A75-M LE AMD Hudson D3 Socket FM1 micro ATX (Depth: 229 mm). Full verified specifications are listed below.
Technical Specifications
Ports & Connectivity
5 SPECS
HDMI ports
0
PS/2 ports
2
DVI-D ports quantity
1
USB 2.0 ports
4
Ethernet ports
1
Memory
2 SPECS
Memory slots
2
Max memory
32 GB
Physical
3 SPECS
Depth
229 mm
Width
244 mm
Form factor
Micro ATX
Processor
2 SPECS
Socket
Socket FM1
CPU brand
AMD
Power
1 SPEC
Power source
ATX
General
43 SPECS
BIOS type
AMI
PCI slots
1
Audio chip
Realtek ALC887
RAID levels
0,1,10,JBOD
ACPI version
2.0a
Intended use
PC
Graphics card
Radeon HD 6000
Microphone input
Yes
LAN controller
Realtek RTL8111E
Included cables
SATA
Memory channels
Dual-channel
BIOS memory size
32 MB
Drivers included
Yes
CPU fan connector
Yes
Headphone outputs
1
ECC сompatibility
non-ECC
Parallel connector
Yes
USB 2.0 connectors
3
Chipset
AMD Hudson D3
Power fan connector
Yes
Graphics card family
AMD
PCI Express x1 slots
1
S/PDIF out connector
Yes
eSATA ports quantity
0
Audio channels
7.1
PCI Express x16 slots
2
Integrated graphics
Yes
Ethernet interface type
Gigabit Ethernet
Number of COM connectors
1
Quick installation guide
Yes
Controller interface type
SATA 6Gb/s
FireWire ports
0
VGA ports
1
Compatible processor series
Intel Pentium Dual-Core
Front panel audio connector
Yes
ATX Power connector (24-pin)
Yes
Number of SATA III connectors
6
Supported memory clock speeds
1066,1333,1600,1866
Number of EATX power connectors
1
Number of chassis fan connectors
1
Number of Parallel ATA connectors
0
USB 3.2 Gen 1 (3.1 Gen 1) connectors
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
