Shuttle logo MPN: NS03A

Shuttle XPC Nano System NS03A, Android OS, Rockchip RK3568, 2 GB RAM, 32GB eMMC, 2 xHDMI, 1x LAN, Wifi, fanless, 24/7 permanent operation

Released: Not on record
Price not yet available US · Amazon.com

We track this product’s Amazon US price daily — it appears here as soon as it’s listed.

Depth
141 mm
Wi-Fi
Y
Width
141 mm
Height
29 mm
Volume
0.577
Weight
270 g
Bluetooth
Y
Audio chip
Rockchip RK809-5
DC-in jack
Y
View 71 specifications
1 / 7
Shopping actions
Check price on Amazon

Overview

The Shuttle XPC nano NS03 series is one of the most affordable models in the Shuttle XPC product range. It not only convinces by its stunning looks and reliable long-term performance alone, it also comes with an integrated Quad-Core ARM processor and pre-installed Android 11 operating system. Two HDMI ports support either two Full HD displays or one 4K display. Featuring 4x USB, Gigabit-LAN, WLAN-ac, M.2 SSD slot and a built-in SD card reader, they easily connect to diverse peripheral devices for different kinds of application. While NS03A is supplied via an included power adapter, NS03E is supplied via the network port (Power-over-Ethernet). The NS03 series is particularly intended for digital signage and Thin Client applications.

Technical Specifications

Physical

8 SPECS
Depth
141 mm
Width
141 mm
Height
29 mm
Weight
270 g
Product type
Mini PC (<= 3L)
Colour
Black
Market segment
Business
Customs (HS) code
84733080

Ports & Connectivity

3 SPECS
HDMI ports
2
USB 2.0 ports
2
Ethernet ports
1

Cooling

1 SPEC
Cooling type
Passive

Processor

6 SPECS
Cores
4
Model
RK3568
Processor line
Rockchip
Process node
22 nm
CPU brand
Rockchip
Boost clock
2 GHz

Memory

3 SPECS
Capacity
2 GB
Memory type
DDR4-SDRAM
Max memory
2 GB

Storage

1 SPEC
Storage
32 GB

Logistics & Packaging

1 SPEC
Package weight
810 g

General

48 SPECS
Wi-Fi
Yes
Volume
0.577
Bluetooth
Yes
Audio chip
Rockchip RK809-5
DC-in jack
Yes
Chassis type
Mini PC
Ethernet LAN
Yes
HDMI version
1.4/2.0
Power supply
36
Storage media
eMMC
VESA mounting
Yes
LAN controller
Realtek RTL8211E
Security lock slot
Yes
Included cables
AC
Wi-Fi standard
802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac)
Display included
No
Housing material
Plastic
Bluetooth version
5.2
Wake-on-LAN ready
Yes
Optical drive type
No
Top Wi-Fi standard
Wi-Fi 5 (802.11ac)
AC adapter included
Yes
VESA mount included
Yes
Cable lock slot type
Kensington
Card reader
Yes
Dedicated graphics
No
Integrated graphics
Yes
Compatible memory cards
SD,SDHC,SDXC
Compliance certificates
BSMI,CB,CE,Federal Communications Commission (FCC),RCM,RoHS,VCCI,cTUVus
Ethernet LAN data rates
10,100,1000
Combo headphone/mic port
Yes
On-board GPU manufacturer
ARM
Sustainability compliance
Yes
Operating system
Android 11
Power supply input voltage
100 - 240
Operating temperature
0 - 40
Eco certifications
ErP
Compatible OS
Android 11, Debian 10 Linux
Dedicated GPU model
Not available
Integrated GPU model
ARM Mali-G52 2EE MC2
Power supply input frequency
50/60
Thunderbolt 3 ports quantity
0
On-board graphics card family
ARM Mali
Operating humidity
10 - 90
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
