MPN:
NC0200U-Q25291
Shuttle XPC nano NC02U Intel® Celeron® 3855U 2 GB DDR3L-SDRAM 32 GB SSD Windows 10 Pro Mini PC Black
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- Depth
- 142 mm
- Wi-Fi
- Y
- Width
- 142 mm
- Height
- 42 mm
- Manual included
- Y
- Volume
- 0.8
- Bus type
- OPI
- DVI port
- N
- 64-bit support
- Y
1 / 6
Shopping actions
Overview
The Shuttle XPC nano NC02U Intel® Celeron® 3855U 2 GB DDR3L-SDRAM 32 GB SSD Windows 10 Pro Mini PC Black features Intel Celeron processor, 2 cores, 2 GB of memory and DDR3L-SDRAM. Full verified specifications are listed below.
Technical Specifications
Processor
13 SPECS
Stepping
D1
Cache
2 MB
Cores
2
Model
3855U
Processor line
Intel Celeron
Socket
BGA 1356
Threads
2
Clock speed
1.6 GHz
Cache level
Smart Cache
Process node
14 nm
CPU brand
Intel
CPU operating modes
64-bit
TDP
15 W
Storage
2 SPECS
Capacity
32 GB
Storage
32 GB
Ports & Connectivity
5 SPECS
HDMI ports
1
PS/2 ports
0
DisplayPorts quantity
1
USB 2.0 ports
2
Ethernet ports
1
Physical
5 SPECS
Depth
142 mm
Width
142 mm
Height
42 mm
Product type
Mini PC (<= 3L)
Colour
Black
Memory
3 SPECS
Capacity
2 GB
Memory type
DDR3L-SDRAM
Max memory
32 GB
General
118 SPECS
Wi-Fi
Yes
Manual included
Yes
Volume
0.8
Bus type
OPI
DVI port
No
64-bit support
Yes
Tjunction
100
Audio chip
Realtek ALC662
DC-in jack
Yes
Idle power states
Yes
Chassis type
Mini PC
Ethernet LAN
Yes
Intel TSX-NI
No
Memory slots
2x SO-DIMM
Power supply
65
On/off button
Yes
Storage media
SSD
VESA mounting
Yes
Processor code
SR2EV
Stand included
Yes
Security lock slot
Yes
Included cables
AC
Memory channels
Dual-channel
Wi-Fi standard
802.11b,802.11g,Wi-Fi 4 (802.11n)
Display included
No
Drivers included
Yes
Intel® OS Guard
No
Intel ARK ID
92211
Processor series
Intel Celeron Processor 3000 Series for Mobile
Headphone outputs
1
Cabling technology
10/100/1000Base-T(X)
Intel® Secure Key
Yes
Optical drive type
No
Codename
Skylake
Top Wi-Fi standard
Wi-Fi 4 (802.11n)
AC adapter included
Yes
Execute Disable (NX)
Yes
Modem (RJ-11) ports
0
VESA mount included
Yes
Cable lock slot type
Kensington
Intel TSX-NI version
0.00
Configurable TDP-down
10
Serial ports
1
Card reader
Yes
Dedicated graphics
No
Integrated graphics
Yes
Processor package size
42 x 24
CPU configuration (max)
1
Compatible memory cards
SD,SDHC,SDXC
Conflict-free minerals
Yes
Ethernet LAN data rates
10,100,1000
Parallel ports
0
Combo headphone/mic port
Yes
Intel Flex Memory Access
Yes
Mini HDMI ports quantity
0
Number of SSDs installed
1
Intel Enhanced Halt State
Yes
On-board graphics card ID
0x1906
PCI Express slots version
2.0
ECC memory support
No
Long-term availability
No
FireWire ports
0
Graphics & IMC lithography
14
Mini DisplayPorts quantity
0
Operating system
Windows 10 Pro
PCI Express configurations
1x2+2x1,1x4,2x2,4x1
Power supply input voltage
100 - 240
Instruction sets
SSE4.1,SSE4.2
Thunderbolt ports quantity
0
VGA ports
0
Dedicated GPU model
Not available
Memory layout (slots x size)
1 x 2
Integrated GPU model
Intel HD Graphics 510
Power supply input frequency
50 - 60
Thunderbolt 2 ports quantity
0
Thunderbolt 3 ports quantity
0
On-board graphics card family
Intel HD Graphics
Intel® Turbo Boost Technology
No
Number of processors installed
1
Thermal monitoring
Yes
Intel® Smart Response Technology
Yes
Trusted Execution (TXT)
No
Number of storage drives installed
1
SpeedStep power scaling
Yes
Intel Secure Key Technology version
1.00
Intel® Quick Sync Video Technology
Yes
PCIe lanes
10
Memory types supported by processor
DDR4-SDRAM,LPDDR3-SDRAM
Maximum on-board graphics card memory
32
On-board graphics card OpenGL version
4.4
On-board graphics card base frequency
300
Virtualization (VT-x)
Yes
On-board graphics card DirectX version
12.0
Intel Smart Response Technology version
1.00
Intel® Wireless Display (Intel® WiDi)
Yes
Intel® My WiFi Technology (Intel® MWT)
Yes
Intel Stable Image Platform Program (SIPP)
No
Intel VT-x with Extended Page Tables (EPT)
Yes
Memory clock speeds supported by processor
1600,1866,2133
Intel Software Guard Extensions (Intel SGX)
Yes
Number of USB ports with PowerShare support
0
Intel Identity Protection Technology version
1.00
Intel Small Business Advantage (SBA) version
0.00
Intel® AES New Instructions (Intel® AES-NI)
Yes
Memory bandwidth supported by processor (max)
34.1
Intel® Small Business Advantage (Intel® SBA)
No
Maximum internal memory supported by processor
32
On-board graphics card dynamic frequency (max)
900
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
Number of displays supported (on-board graphics)
3
Intel Stable Image Platform Program (SIPP) version
0.00
Intel® Clear Video HD Technology (Intel® CVT HD)
Yes
Intel® Identity Protection Technology (Intel® IPT)
Yes
Directed I/O virtualization (VT-d)
Yes
Intel® Hyper Threading Technology (Intel® HT Technology)
No
