MPN:
10TV007KTX
Lenovo V530 Intel® Core™ i5 i5-9400 4 GB DDR4-SDRAM 1 TB HDD Tower PC Black
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- Depth
- 276 mm
- Wi-Fi
- N
- Width
- 145 mm
- Height
- 360 mm
- Volume
- 15
- Weight
- 5700 g
- Line-in
- Y
- Bus type
- DMI3
- DVI port
- N
1 / 4
Shopping actions
Overview
The Lenovo V530 Intel® Core™ i5 i5-9400 4 GB DDR4-SDRAM 1 TB HDD Tower PC Black features Intel Core i5 processor, 6 cores, up to 4.1 GHz boost and 4 GB of memory. Full verified specifications are listed below.
Technical Specifications
Processor
13 SPECS
Cache
9 MB
Cores
6
Model
i5-9400
Processor line
Intel Core i5
Socket
LGA 1151 (Socket H4)
Threads
6
Clock speed
2.9 GHz
Cache level
Smart Cache
Process node
14 nm
CPU brand
Intel
Boost clock
4.1 GHz
CPU operating modes
64-bit
TDP
65 W
Storage
2 SPECS
Capacity
1 TB
Storage
1 TB
Graphics
1 SPEC
Memory clock
2666 MHz
Physical
6 SPECS
Depth
276 mm
Width
145 mm
Height
360 mm
Weight
5700 g
Product type
PC
Colour
Black
Ports & Connectivity
4 SPECS
HDMI ports
1
DisplayPorts quantity
1
USB 2.0 ports
4
Ethernet ports
1
Memory
3 SPECS
Capacity
4 GB
Memory type
DDR4-SDRAM
Max memory
32 GB
General
107 SPECS
Wi-Fi
No
Volume
15
Line-in
Yes
Bus type
DMI3
DVI port
No
Drive form factor
3.5
64-bit support
Yes
Line-out
Yes
Spindle speed
7200 rpm
Tjunction
100
Audio chip
Realtek ALC662
Idle power states
Yes
Scalability
1S
Audio system
High Definition Audio
Chassis type
Tower
Ethernet LAN
Yes
Intel TSX-NI
No
Memory slots
2x DIMM
Power supply
180
Drive interface
SATA III
Microphone input
Yes
Storage media
HDD
Mouse included
Yes
Memory channels
Dual-channel
Bus speed
8 GT/s
Display included
No
Housing material
Metal
Intel® OS Guard
Yes
Intel ARK ID
134898
Headphone outputs
1
Keyboard included
Yes
Cabling technology
10/100/1000Base-T(X)
Intel® Secure Key
Yes
Optical drive type
DVD±RW
Codename
Coffee Lake
Execute Disable (NX)
Yes
Chipset
Intel B360
Password protection
Yes
Placement supported
Vertical
Total HDDs capacity
1000
Intel TSX-NI version
0.00
Generation
Intel Core i5-9xxx
Card reader
Yes
Dedicated graphics
No
Integrated graphics
Yes
Processor package size
37.5 x 37.5
CPU configuration (max)
1
Compatible memory cards
MMC,MMC+,MS PRO,Memory Stick (MS),SD,SDHC,SDXC
Compliance certificates
RoHS
Ethernet LAN data rates
10,100,1000
Optical drives quantity
1
Number of HDDs installed
1
Password protection type
Power on,Supervisor
Intel Enhanced Halt State
Yes
On-board graphics card ID
0X3E98/x92
PCI Express slots version
3.0
Long-term availability
No
Operating system
No
PCI Express configurations
1x8+2x4,1x16,2x8
Power supply input voltage
100 - 240
Instruction sets
AVX 2.0,SSE4.1,SSE4.2
VGA ports
1
Eco certifications
ENERGY STAR
Dedicated GPU model
Not available
Intel Clear Video Technology
Yes
Memory layout (slots x size)
1 x 4
Integrated GPU model
Intel UHD Graphics 630
Power supply input frequency
50 - 60
Thunderbolt 3 ports quantity
0
On-board graphics card family
Intel UHD Graphics
Trusted Platform Module (TPM)
Yes
Intel® InTru™ 3D Technology
Yes
Intel® Turbo Boost Technology
2.0
Number of processors installed
1
Thermal solution specification
PCG 2015C
Thermal monitoring
Yes
Trusted Execution (TXT)
No
SpeedStep power scaling
Yes
Intel Secure Key Technology version
1.00
Intel® Quick Sync Video Technology
Yes
PCIe lanes
16
Memory types supported by processor
DDR4-SDRAM
Maximum on-board graphics card memory
64
On-board graphics card OpenGL version
4.5
On-board graphics card base frequency
350
Virtualization (VT-x)
Yes
On-board graphics card DirectX version
12.0
Intel Stable Image Platform Program (SIPP)
No
Intel VT-x with Extended Page Tables (EPT)
Yes
Memory clock speeds supported by processor
2666
Intel Software Guard Extensions (Intel SGX)
Yes
Intel Identity Protection Technology version
1.00
Intel® AES New Instructions (Intel® AES-NI)
Yes
Memory bandwidth supported by processor (max)
41.6
Maximum internal memory supported by processor
128
On-board graphics card dynamic frequency (max)
1050
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
Number of displays supported (on-board graphics)
3
Intel Stable Image Platform Program (SIPP) version
0.00
Intel® Clear Video HD Technology (Intel® CVT HD)
Yes
Intel® Identity Protection Technology (Intel® IPT)
Yes
Directed I/O virtualization (VT-d)
Yes
Intel® Hyper Threading Technology (Intel® HT Technology)
No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
Yes
