Lenovo logo MPN: 30F30055US

Lenovo ThinkStation P7 Intel Xeon W w5-3435X 32 GB DDR5-SDRAM 1 TB SSD NVIDIA RTX A2000 Windows 11 Pro for Workstations Tower Workstation Black, Red

Released: Not on record
Price not yet available US · Amazon.com

We track this product’s Amazon US price daily — it appears here as soon as it’s listed.

ECC support
Y
NVMe
Y
Depth
508 mm
Wi-Fi
Y
Width
175 mm
Height
440.4 mm
Volume
39
Weight
24500 g
Line-in
Y
View 109 specifications
1 / 7
Shopping actions
Check price on Amazon

Overview

ThinkStation P7

This powerful workstation with a scalable architecture and equipped with Intel Xeon Series processor exceeds everyday computing experience. With up to 1TB ultrafast DDR5-4800 memory, it promises speedy upgrades and load times for data- rich files or gaming apps. Configure it to suit your business needs by selecting from a list of discrete NVIDIA graphics, optional OS including windows 11 or Red Hat Enterprise Linux, and up to 9x M.2 SSD drives.

A self-healing BIOS provides a secure backup, and restores the data and device in case of malicious ransomware attacks. TPM 2.0 encrypts data, passwords end-to-end while Kensington security slot and optional access panel lock kit protect the device physically.

Up to 9x high-speed PCIe expansion slots means countless customization options – connect a graphics card for online gaming, or a Wi-Fi network card for added functionalities.

It has up to 1TB DDR5-4800 memory that ensures speedy upgrades and load times for compute-intensive tasks and heavy-duty applications.

Technical Specifications

Processor

10 SPECS
Cache
45 MB
Cores
16
Model
w5-3435X
Processor line
Intel Xeon W
Socket
LGA 4677 (Socket E)
Threads
32
Clock speed
3.1 GHz
Cache level
Smart Cache
CPU brand
Intel
Boost clock
4.7 GHz

Storage

3 SPECS
Capacity
1 TB
Form factor
M.2
Storage
1 TB

Graphics

2 SPECS
Memory clock
4800 MHz
VRAM
12 GB

Physical

6 SPECS
Depth
508 mm
Width
175 mm
Height
440.4 mm
Weight
24500 g
Product type
Workstation
Colour
Black,Red

Memory

4 SPECS
ECC support
Yes
Capacity
32 GB
Memory type
DDR5-SDRAM
Max memory
1000 GB

Ports & Connectivity

3 SPECS
HDMI ports
0
USB 2.0 ports
2
Ethernet ports
2

Power

1 SPEC
Efficiency rating
80 PLUS Platinum

General

80 SPECS
NVMe
Yes
Wi-Fi
Yes
Volume
39
Line-in
Yes
Non-ECC
No
Line-out
Yes
BIOS type
UEFI
Bluetooth
Yes
Audio chip
Realtek ALC897-Q
Antenna type
2x2
Audio system
High Definition Audio
Chassis type
Tower
Ethernet LAN
Yes
M.2 SSD size
2280 (22 x 80 mm)
Memory slots
8x DIMM
Power supply
1400
Certifications
TCG certified, FIPS 140-2 certified, TCO Certified 9.0
Rack capacity
4U
SSD interface
PCI Express 4.0
Storage media
SSD
LAN controller
Intel I219-LM,Marvell AQtion AQC113C
Mouse included
Yes
Efficient cores
0
Keyboard layout
QWERTY
Memory channels
Octa-channel
Wi-Fi standard
802.11ad,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax),Wi-Fi 6E (802.11ax)
Display included
No
Bluetooth version
5.1
Keyboard included
Yes
Performance cores
16
Mouse connectivity
Wired
Number of speakers
1
Operating altitude
0 - 3048
Optical drive type
No
Top Wi-Fi standard
Wi-Fi 6E (802.11ax)
Built-in speaker(s)
Yes
Maximum turbo power
324
Chipset
Intel W790
Password protection
Yes
Placement supported
Horizontal/Vertical
Total SSDs capacity
1000
Processor base power
270
Keyboard connectivity
Wired
WLAN controller model
Intel Wi-Fi 6E AX210
Card reader
Yes
Dedicated graphics
Yes
Non-operating altitude
0 - 12192
Integrated graphics
No
Compliance certificates
RoHS
Ethernet LAN data rates
10,1000,100,10000
Combo headphone/mic port
Yes
Number of SSDs installed
1
Password protection type
Power on,Supervisor
Discrete GPU manufacturer
NVIDIA
Operating system language
ENG
PCI Express slots version
4.0,5.0
Storage temperature
-40 - 60
Operating system
Windows 11 Pro for Workstations
Operating temperature
10 - 35
Eco certifications
ENERGY STAR,EPEAT Gold,TCO
Dedicated GPU model
NVIDIA RTX A2000
Memory layout (slots x size)
2 x 16
Integrated GPU model
Not available
Thunderbolt 3 ports quantity
0
WLAN controller manufacturer
Intel
OS architecture
64-bit
Trusted Platform Module (TPM)
Yes
Intel® Turbo Boost Technology
3.0
Storage relative humidity (H-H)
10 - 90
Number of discrete graphics cards
1
Operating humidity
20 - 80
Number of storage drives installed
1
Performance-core Max Turbo Frequency
4.7
Trusted Platform Module (TPM) version
2.0
USB 3.2 Gen 2x2 Type-C ports quantity
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
5
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
2
Intel® Turbo Boost Max Technology 3.0 frequency
4.7
