Lenovo logo MPN: 30DK004RGE

Lenovo ThinkStation P340 Intel® Core™ i7 i7-10700 16 GB DDR4-SDRAM 512 GB SSD Windows 10 Pro SFF Workstation Black

Released: Not on record
Price not yet available US · Amazon.com

We track this product’s Amazon US price daily — it appears here as soon as it’s listed.

NVMe
Y
Depth
309.7 mm
Wi-Fi
N
Width
92.5 mm
Height
339.5 mm
Volume
8.2
Weight
5650 g
Non-ECC
Y
DVI port
N
View 95 specifications
1 / 8
Shopping actions
Check price on Amazon

Overview

When multiple displays are a must
The ThinkStation P340 SFF is a stylish, compact choice for workstation users in fields like architecture, finance, and health care. With up to three DisplayPort™ ports, this workstation supports up to 11 independent displays. It also boasts ISV certifications from all the major vendors, including Autodesk®, Bentley®, Dassault®, PTC®, and Siemens®.

Compact powerhouse
Enjoy cutting-edge workstation performance on the space-saving ThinkStation P340 SFF. The latest Intel® Xeon® or Intel® Core™ vPro™ processors power even the most intensive tasks. Add in NVIDIA® Quadro® graphics and dual M.2 PCIe storage with RAID for an even more potent combination.

Rugged, secure, & expandable
Lenovo’s legendary reliability ensures the ThinkStation P340 small form factor workstation is built to last—even in extreme conditions. Your data will remain safe, too: The integrated suite of ThinkShield security solutions includes discrete Trusted Platform Module (dTPM) to encrypt your data. And easy component access means you can expand as your business grows.

Technical Specifications

Processor

9 SPECS
Cache
16 MB
Cores
8
Model
i7-10700
Processor line
Intel Core i7
Threads
16
Clock speed
2.9 GHz
Cache level
Smart Cache
CPU brand
Intel
Boost clock
4.8 GHz

Storage

3 SPECS
Capacity
512 GB
Form factor
M.2
Storage
512 GB

Graphics

1 SPEC
Memory clock
2933 MHz

Physical

6 SPECS
Depth
309.7 mm
Width
92.5 mm
Height
339.5 mm
Weight
5650 g
Product type
Workstation
Colour
Black

Memory

3 SPECS
Capacity
16 GB
Memory type
DDR4-SDRAM
Max memory
128 GB

Ports & Connectivity

3 SPECS
DisplayPorts quantity
2
USB 2.0 ports
2
Ethernet ports
1

General

70 SPECS
NVMe
Yes
Wi-Fi
No
Volume
8.2
Non-ECC
Yes
DVI port
No
64-bit support
Yes
Line-out
Yes
Audio chip
Realtek ALC623
Idle power states
Yes
Audio system
High Definition Audio
Chassis type
SFF
Ethernet LAN
Yes
Memory slots
4x DIMM
Power supply
310
Microphone input
Yes
SSD interface
NVMe,PCI Express
Storage media
SSD
LAN controller
Intel I219-LM
Mouse included
Yes
Security lock slot
Yes
Memory channels
Dual-channel
Headphone outputs
1
Keyboard included
Yes
Cabling technology
10/100/1000Base-T(X)
Operating altitude
0 - 3048
Optical drive type
No
Execute Disable (NX)
Yes
Chipset
Intel W480
Password protection
Yes
Placement supported
Horizontal/Vertical
Total SSDs capacity
512
Cable lock slot type
Kensington
Generation
Intel Core i7-10xxx
Card reader
No
Dedicated graphics
No
Non-operating altitude
0 - 12192
Integrated graphics
Yes
CPU configuration (max)
1
Ethernet LAN data rates
1000
Number of SSDs installed
1
Password protection type
Power on,Supervisor
On-board GPU manufacturer
Intel
Operating system language
DEU
Storage temperature
-40 - 60
Long-term availability
No
Operating system
Windows 10 Pro
Power supply input voltage
100 - 240
Operating temperature
10 - 35
Eco certifications
ENERGY STAR,EPEAT Silver
Dedicated GPU model
Not available
Intel Clear Video Technology
Yes
Memory layout (slots x size)
2 x 8
Integrated GPU model
Intel UHD Graphics 630
OS architecture
64-bit
Trusted Platform Module (TPM)
Yes
Number of processors installed
1
Storage relative humidity (H-H)
10 - 90
Operating humidity
20 - 80
Trusted Execution (TXT)
Yes
Number of storage drives installed
1
SpeedStep power scaling
Yes
Virtualization (VT-x)
Yes
Intel Stable Image Platform Program (SIPP)
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
Intel Software Guard Extensions (Intel SGX)
Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
Directed I/O virtualization (VT-d)
Yes
