MPN:
30BH000BMB
Lenovo ThinkStation P320 Intel® Core™ i7 i7-7700K 16 GB DDR4-SDRAM 512 GB SSD Windows 10 Pro Tower Workstation Black
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- Depth
- 426 mm
- Wi-Fi
- N
- Width
- 175 mm
- Height
- 376 mm
- Weight
- 13000 g
- Line-in
- Y
- Non-ECC
- Y
- Bus type
- DMI3
- DVI port
- N
1 / 6
Shopping actions
Overview
The Lenovo ThinkStation P320 Intel® Core™ i7 i7-7700K 16 GB DDR4-SDRAM 512 GB SSD Windows 10 Pro Tower Workstation Black features Intel Core i7 processor, 4 cores, up to 4.5 GHz boost and 16 GB of memory. Full verified specifications are listed below.
Technical Specifications
Processor
14 SPECS
Stepping
B0
Cache
8 MB
Cores
4
Model
i7-7700K
Processor line
Intel Core i7
Socket
LGA 1151 (Socket H4)
Threads
8
Clock speed
4.2 GHz
Cache level
Smart Cache
Process node
14 nm
CPU brand
Intel
Boost clock
4.5 GHz
CPU operating modes
64-bit
TDP
91 W
Storage
2 SPECS
Capacity
512 GB
Storage
512 GB
Physical
6 SPECS
Depth
426 mm
Width
175 mm
Height
376 mm
Weight
13000 g
Product type
Workstation
Colour
Black
Ports & Connectivity
4 SPECS
HDMI ports
0
DisplayPorts quantity
2
USB 2.0 ports
2
Ethernet ports
1
Memory
3 SPECS
Capacity
16 GB
Memory type
DDR4-SDRAM
Max memory
64 GB
Graphics
1 SPEC
Memory clock
2400 MHz
General
98 SPECS
Wi-Fi
No
Line-in
Yes
Non-ECC
Yes
Bus type
DMI3
DVI port
No
64-bit support
Yes
Line-out
Yes
Tjunction
100
Idle power states
Yes
Scalability
1S
Chassis type
Tower
Ethernet LAN
Yes
Intel TSX-NI
Yes
Memory slots
4x DIMM
Power supply
400
Microphone input
Yes
Storage media
SSD
Mouse included
Yes
Processor code
SR338
Memory channels
Dual-channel
Bus speed
8 GT/s
Display included
No
Intel® OS Guard
Yes
Intel ARK ID
97129
Processor series
Intel Core i7-7700 Desktop Series
Headphone outputs
1
Keyboard included
Yes
Cabling technology
10/100/1000Base-T(X)
Intel® Secure Key
Yes
Optical drive type
DVD±RW
Codename
Kaby Lake
Execute Disable (NX)
Yes
Chipset
Intel C236
Number of QPI links
0
Placement supported
Vertical
Intel TSX-NI version
1.00
Generation
Intel Core i7-7xxx
Card reader
Yes
Dedicated graphics
No
Integrated graphics
Yes
Processor package size
37.5 x 37.5
CPU configuration (max)
1
Conflict-free minerals
Yes
Ethernet LAN data rates
10,100,1000
Optical drives quantity
1
Number of SSDs installed
1
Intel Enhanced Halt State
Yes
On-board graphics card ID
0x5912
PCI Express slots version
3.0
ECC memory support
No
Long-term availability
No
Operating system
Windows 10 Pro
PCI Express configurations
1x16,1x8+2x4,2x8
Instruction sets
AVX 2.0,SSE4.1,SSE4.2
VGA ports
1
Eco certifications
Blue Angel,EPEAT Gold,ENERGY STAR
Dedicated GPU model
Not available
Intel Clear Video Technology
Yes
Memory layout (slots x size)
2 x 8
Integrated GPU model
Intel HD Graphics 630
Thunderbolt 3 ports quantity
0
OS architecture
64-bit
Intel® InTru™ 3D Technology
Yes
Intel® Turbo Boost Technology
2.0
Number of processors installed
1
Thermal solution specification
PCG 2015D
Thermal monitoring
Yes
Number of storage drives installed
1
SpeedStep power scaling
Yes
Intel Secure Key Technology version
1.00
Intel® Quick Sync Video Technology
Yes
PCIe lanes
16
Memory types supported by processor
DDR3L-SDRAM,DDR4-SDRAM
Maximum on-board graphics card memory
64
Memory voltage supported by processor
1.35
On-board graphics card OpenGL version
4.4
On-board graphics card base frequency
350
Virtualization (VT-x)
Yes
On-board graphics card DirectX version
12.0
Intel Stable Image Platform Program (SIPP)
No
Intel VT-x with Extended Page Tables (EPT)
Yes
Memory clock speeds supported by processor
1333,1600,2133,2400
Intel Software Guard Extensions (Intel SGX)
Yes
Intel Identity Protection Technology version
1.00
Intel® AES New Instructions (Intel® AES-NI)
Yes
Maximum internal memory supported by processor
64
On-board graphics card dynamic frequency (max)
1150
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
6
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
Number of displays supported (on-board graphics)
3
Intel Stable Image Platform Program (SIPP) version
0.00
Intel® Clear Video HD Technology (Intel® CVT HD)
Yes
Intel® Identity Protection Technology (Intel® IPT)
Yes
Directed I/O virtualization (VT-d)
Yes
Intel® Hyper Threading Technology (Intel® HT Technology)
Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
Yes
