MPN:
11AKS00Y00
Lenovo ThinkCentre M90n-1 Nano IoT Intel® Core™ i3 i3-8145U 4 GB DDR4-SDRAM 256 GB SSD Windows 10 Pro Mini PC Black
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- ECC support
- N
- Depth
- 88 mm
- Width
- 179 mm
- Height
- 34.5 mm
- Volume
- 0.55
- Weight
- 720 g
- Non-ECC
- Y
- Bus type
- OPI
- DVI port
- N
1 / 8
Shopping actions
Overview
The Lenovo ThinkCentre M90n-1 Nano IoT Intel® Core™ i3 i3-8145U 4 GB DDR4-SDRAM 256 GB SSD Windows 10 Pro Mini PC Black features Intel Core i3 processor, 2 cores, up to 3.9 GHz boost and 4 GB of memory. Full verified specifications are listed below.
Technical Specifications
Processor
13 SPECS
Cache
4 MB
Cores
2
Model
i3-8145U
Processor line
Intel Core i3
Socket
BGA 1528
Threads
4
Clock speed
2.1 GHz
Cache level
Smart Cache
Process node
14 nm
CPU brand
Intel
Boost clock
3.9 GHz
CPU operating modes
64-bit
TDP
15 W
Storage
2 SPECS
Capacity
256 GB
Storage
256 GB
Physical
6 SPECS
Depth
88 mm
Width
179 mm
Height
34.5 mm
Weight
720 g
Product type
Mini PC (<= 3L)
Colour
Black
Memory
4 SPECS
ECC support
No
Capacity
4 GB
Memory type
DDR4-SDRAM
Max memory
4 GB
Ports & Connectivity
3 SPECS
HDMI ports
0
USB 2.0 ports
0
Ethernet ports
2
General
100 SPECS
Volume
0.55
Non-ECC
Yes
Bus type
OPI
DVI port
No
64-bit support
Yes
Tjunction
100
Audio chip
Realtek ALC233VB
Idle power states
Yes
Audio system
High Definition Audio
Chassis type
Mini PC
Ethernet LAN
Yes
Intel TSX-NI
No
Power supply
65
Microphone input
No
Storage media
SSD
Security lock slot
Yes
Bus speed
4 GT/s
Display included
No
Intel® OS Guard
Yes
Intel ARK ID
149090
Headphone outputs
1
Cabling technology
10/100/1000Base-T(X)
Intel® Secure Key
Yes
Number of speakers
1
Optical drive type
No
Codename
Whiskey Lake
Built-in speaker(s)
Yes
Configurable TDP-up
25
Execute Disable (NX)
Yes
Password protection
Yes
Placement supported
Horizontal/Vertical
Total SSDs capacity
256
Cable lock slot type
Kensington
Intel TSX-NI version
0.00
Generation
Intel Core i3-8xxx
Configurable TDP-down
10
Serial ports
2
Card reader
No
Dedicated graphics
No
Integrated graphics
Yes
Processor package size
46x24
CPU configuration (max)
1
Compliance certificates
RoHS
Ethernet LAN data rates
10,100,1000
Combo headphone/mic port
Yes
Intel Flex Memory Access
Yes
Number of SSDs installed
1
Password protection type
HDD,Power on,Supervisor
Intel Enhanced Halt State
Yes
On-board GPU manufacturer
Intel
On-board graphics card ID
0x3EA0
PCI Express slots version
3.0
Long-term availability
No
Operating system
Windows 10 Pro
PCI Express configurations
1x2+2x1,1x4,2x2,4x1
Instruction sets
AVX 2.0,SSE4.1,SSE4.2
Eco certifications
ENERGY STAR
Dedicated GPU model
Not available
Intel Clear Video Technology
Yes
Integrated GPU model
Intel UHD Graphics
Thunderbolt 3 ports quantity
0
Configurable TDP-up frequency
2.3
OS architecture
64-bit
Intel® Turbo Boost Technology
2.0
Number of processors installed
1
Configurable TDP-down frequency
0.8
Thermal monitoring
Yes
Intel® Smart Response Technology
Yes
Trusted Execution (TXT)
No
Number of storage drives installed
1
SpeedStep power scaling
Yes
Intel Secure Key Technology version
1.00
Intel® Quick Sync Video Technology
Yes
PCIe lanes
16
Memory types supported by processor
DDR4-SDRAM,LPDDR3-SDRAM
Maximum on-board graphics card memory
32
On-board graphics card OpenGL version
4.5
On-board graphics card base frequency
300
Virtualization (VT-x)
Yes
On-board graphics card DirectX version
12.0
Intel Smart Response Technology version
1.00
Intel® My WiFi Technology (Intel® MWT)
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
Memory clock speeds supported by processor
2133,2400
Intel Software Guard Extensions (Intel SGX)
Yes
Intel Identity Protection Technology version
1.00
Intel® AES New Instructions (Intel® AES-NI)
Yes
Memory bandwidth supported by processor (max)
37.5
Maximum internal memory supported by processor
32
On-board graphics card dynamic frequency (max)
1000
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
2
Number of displays supported (on-board graphics)
3
Intel® Clear Video HD Technology (Intel® CVT HD)
Yes
Intel® Identity Protection Technology (Intel® IPT)
Yes
Directed I/O virtualization (VT-d)
Yes
Intel® Hyper Threading Technology (Intel® HT Technology)
Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
Yes
Market Value History
Price history not started yet
Daily price tracking begins as soon as this product is listed on Amazon US — the trend chart will appear here automatically.
Sources
Product lifecycle
In production
Still listed as on-market by the manufacturer — actively sold and supported.
Lifecycle status is derived from catalog data and is indicative, not a manufacturer support guarantee.
