MPN:
11AD0025US
Lenovo ThinkCentre M90n-1 Nano Intel® Core™ i7 i7-8665U 16 GB DDR4-SDRAM 1 TB SSD Windows 10 Pro Mini PC Black
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- Depth
- 88 mm
- Wi-Fi
- Y
- Width
- 179 mm
- Height
- 22 mm
- Volume
- 0.35
- Weight
- 505 g
- DVI port
- N
- 64-bit support
- Y
- Bluetooth
- Y
1 / 8
Shopping actions
Overview
The Lenovo ThinkCentre M90n-1 Nano Intel® Core™ i7 i7-8665U 16 GB DDR4-SDRAM 1 TB SSD Windows 10 Pro Mini PC Black features Intel Core i7 processor, 4 cores, up to 4.8 GHz boost and 16 GB of memory. Full verified specifications are listed below.
Technical Specifications
Processor
13 SPECS
Cache
8 MB
Cores
4
Model
i7-8665U
Processor line
Intel Core i7
Socket
BGA 1528
Threads
8
Clock speed
1.9 GHz
Cache level
Smart Cache
Process node
14 nm
CPU brand
Intel
Boost clock
4.8 GHz
CPU operating modes
64-bit
TDP
15 W
Storage
3 SPECS
Capacity
512 GB
Form factor
M.2
Storage
1024 GB
Physical
6 SPECS
Depth
88 mm
Width
179 mm
Height
22 mm
Weight
505 g
Product type
Mini PC (<= 3L)
Colour
Black
Ports & Connectivity
4 SPECS
HDMI ports
0
DisplayPorts quantity
1
USB 2.0 ports
0
Ethernet ports
1
Memory
3 SPECS
Capacity
16 GB
Memory type
DDR4-SDRAM
Max memory
16 GB
Graphics
1 SPEC
Memory clock
2400 MHz
General
103 SPECS
Wi-Fi
Yes
Volume
0.35
DVI port
No
64-bit support
Yes
Bluetooth
Yes
Tjunction
100
Audio chip
Realtek ALC233VB
DC-in jack
Yes
Idle power states
Yes
Antenna type
2x2
Audio system
High Definition Audio
Chassis type
Mini PC
Ethernet LAN
Yes
Intel TSX-NI
Yes
Power supply
65
Certifications
ErP Lot 3
TCO 8.0
WEEE
REACH
MIL-STD-810H
Microphone input
No
SSD interface
PCI Express
Storage media
SSD
Mouse included
Yes
Bus speed
4 GT/s
Wi-Fi standard
802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac)
Display included
No
Housing material
Metal
Intel® OS Guard
Yes
Intel ARK ID
193563
Bluetooth version
5.0
Headphone outputs
1
Keyboard included
Yes
Cabling technology
10/100/1000Base-T(X)
Intel® Secure Key
Yes
Optical drive type
No
Codename
Whiskey Lake
Top Wi-Fi standard
Wi-Fi 5 (802.11ac)
Configurable TDP-up
25
Execute Disable (NX)
Yes
Chipset
Intel SoC
Password protection
Yes
Placement supported
Horizontal
Total SSDs capacity
1024
Generation
Intel Core i7-8xxx
Configurable TDP-down
10
WLAN controller model
Intel Dual Band Wireless-AC 9560
Card reader
No
Dedicated graphics
No
Integrated graphics
Yes
Processor package size
46x24
CPU configuration (max)
1
Compliance certificates
RoHS
Ethernet LAN data rates
10,100,1000
Combo headphone/mic port
Yes
Intel Flex Memory Access
Yes
Number of SSDs installed
2
Password protection type
HDD,Power on,Supervisor
On-board graphics card ID
0x3EA0
PCI Express slots version
3.0
Long-term availability
No
Operating system
Windows 10 Pro
PCI Express configurations
1x4,2x2,1x2+2x1,4x1
Instruction sets
SSE4.1,SSE4.2,AVX 2.0
VGA ports
0
Eco certifications
EPEAT Silver,ENERGY STAR
Dedicated GPU model
Not available
Intel Clear Video Technology
Yes
Integrated GPU model
Intel UHD Graphics 620
Thunderbolt 3 ports quantity
0
Configurable TDP-up frequency
2.1
On-board graphics card family
Intel UHD Graphics
OS architecture
64-bit
Trusted Platform Module (TPM)
Yes
Intel® Turbo Boost Technology
2.0
Number of processors installed
1
Configurable TDP-down frequency
0.8
Thermal monitoring
Yes
Intel® Smart Response Technology
Yes
Trusted Execution (TXT)
Yes
SpeedStep power scaling
Yes
Intel® Quick Sync Video Technology
Yes
PCIe lanes
16
Memory types supported by processor
DDR4-SDRAM,LPDDR3-SDRAM
Maximum on-board graphics card memory
32
On-board graphics card OpenGL version
4.5
On-board graphics card base frequency
300
Virtualization (VT-x)
Yes
On-board graphics card DirectX version
12.0
Intel® My WiFi Technology (Intel® MWT)
Yes
Intel Stable Image Platform Program (SIPP)
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
Memory clock speeds supported by processor
2400,2133
Intel Software Guard Extensions (Intel SGX)
Yes
Intel® AES New Instructions (Intel® AES-NI)
Yes
Memory bandwidth supported by processor (max)
37.5
Maximum internal memory supported by processor
32
On-board graphics card dynamic frequency (max)
1150
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
2
Number of displays supported (on-board graphics)
3
Intel® Clear Video HD Technology (Intel® CVT HD)
Yes
Intel® Identity Protection Technology (Intel® IPT)
Yes
Directed I/O virtualization (VT-d)
Yes
Intel® Hyper Threading Technology (Intel® HT Technology)
Yes
Market Value History
Sources
Product lifecycle
In production
Still listed as on-market by the manufacturer — actively sold and supported.
Lifecycle status is derived from catalog data and is indicative, not a manufacturer support guarantee.
