MPN:
10STA01DAU
Lenovo ThinkCentre M720s Intel® Core™ i5 i5-9400 16 GB DDR4-SDRAM 512 GB SSD Windows 10 Pro SFF PC Black
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- NVMe
- Y
- Depth
- 290.5 mm
- Wi-Fi
- N
- Width
- 92.5 mm
- Height
- 343.5 mm
- Volume
- 8.4
- Weight
- 6000 g
- Non-ECC
- Y
- Bus type
- DMI3
1 / 5
Shopping actions
Overview
The Lenovo ThinkCentre M720s Intel® Core™ i5 i5-9400 16 GB DDR4-SDRAM 512 GB SSD Windows 10 Pro SFF PC Black features Intel Core i5 processor, 6 cores, up to 4.1 GHz boost, 16 GB of memory and NVMe support. Full verified specifications are listed below.
Technical Specifications
Processor
13 SPECS
Cache
9 MB
Cores
6
Model
i5-9400
Processor line
Intel Core i5
Socket
LGA 1151 (Socket H4)
Threads
6
Clock speed
2.9 GHz
Cache level
Smart Cache
Process node
14 nm
CPU brand
Intel
Boost clock
4.1 GHz
CPU operating modes
64-bit
TDP
65 W
Storage
3 SPECS
Capacity
512 GB
Form factor
M.2
Storage
512 GB
Physical
6 SPECS
Depth
290.5 mm
Width
92.5 mm
Height
343.5 mm
Weight
6000 g
Product type
PC
Colour
Black
Ports & Connectivity
4 SPECS
HDMI ports
0
DisplayPorts quantity
2
USB 2.0 ports
4
Ethernet ports
1
Memory
3 SPECS
Capacity
16 GB
Memory type
DDR4-SDRAM
Max memory
64 GB
Graphics
1 SPEC
Memory clock
2666 MHz
General
97 SPECS
NVMe
Yes
Wi-Fi
No
Volume
8.4
Non-ECC
Yes
Bus type
DMI3
DVI port
No
64-bit support
Yes
Line-out
Yes
Tjunction
100
Audio chip
Realtek ALC233VB2
Idle power states
Yes
Scalability
1S
Audio system
High Definition Audio
Chassis type
SFF
Ethernet LAN
Yes
Intel TSX-NI
No
Memory slots
4x DIMM
Power supply
210
Microphone input
Yes
SSD interface
NVMe,PCI Express 3.0
Storage media
SSD
Mouse included
Yes
Bus speed
8 GT/s
Display included
No
Intel® OS Guard
Yes
Intel ARK ID
134898
Headphone outputs
1
Keyboard included
Yes
Cabling technology
10/100/1000Base-T(X)
Intel® Secure Key
Yes
Optical drive type
DVD±RW
Codename
Coffee Lake
Execute Disable (NX)
Yes
Chipset
Intel B360
Total SSDs capacity
512
Intel TSX-NI version
0.00
Generation
Intel Core i5-9xxx
Serial ports
1
Card reader
No
Dedicated graphics
No
Integrated graphics
Yes
Processor package size
37.5 x 37.5
CPU configuration (max)
1
Compliance certificates
RoHS
Ethernet LAN data rates
10,100,1000
Number of SSDs installed
1
Intel Enhanced Halt State
Yes
On-board graphics card ID
0X3E98/x92
PCI Express slots version
3.0
Long-term availability
No
Operating system
Windows 10 Pro
PCI Express configurations
1x8+2x4,1x16,2x8
Instruction sets
AVX 2.0,SSE4.1,SSE4.2
VGA ports
1
Eco certifications
ENERGY STAR
Dedicated GPU model
Not available
Intel Clear Video Technology
Yes
Memory layout (slots x size)
2 x 8
Integrated GPU model
Intel UHD Graphics 630
OS architecture
64-bit
Intel® InTru™ 3D Technology
Yes
Intel® Turbo Boost Technology
2.0
Number of processors installed
1
Thermal solution specification
PCG 2015C
Thermal monitoring
Yes
Trusted Execution (TXT)
No
Number of storage drives installed
1
SpeedStep power scaling
Yes
Intel Secure Key Technology version
1.00
Intel® Quick Sync Video Technology
Yes
PCIe lanes
16
Memory types supported by processor
DDR4-SDRAM
Maximum on-board graphics card memory
64
On-board graphics card OpenGL version
4.5
On-board graphics card base frequency
350
Virtualization (VT-x)
Yes
On-board graphics card DirectX version
12.0
Intel Stable Image Platform Program (SIPP)
No
Intel VT-x with Extended Page Tables (EPT)
Yes
Memory clock speeds supported by processor
2666
Intel Software Guard Extensions (Intel SGX)
Yes
Intel Identity Protection Technology version
1.00
Intel® AES New Instructions (Intel® AES-NI)
Yes
Memory bandwidth supported by processor (max)
41.6
Maximum internal memory supported by processor
128
On-board graphics card dynamic frequency (max)
1050
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
Number of displays supported (on-board graphics)
3
Intel Stable Image Platform Program (SIPP) version
0.00
Intel® Clear Video HD Technology (Intel® CVT HD)
Yes
Intel® Identity Protection Technology (Intel® IPT)
Yes
Directed I/O virtualization (VT-d)
Yes
Intel® Hyper Threading Technology (Intel® HT Technology)
No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
Yes
