MPN:
RCFKAML
Lenovo ThinkCentre Edge 72 Intel® Core™ i3 i3-3240 4 GB DDR3-SDRAM 500 GB HDD Windows 7 Professional SFF PC Black
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- Depth
- 382 mm
- Max case temperature (Tcase)
- 65.3 °C
- Width
- 336 mm
- Height
- 101 mm
- Weight
- 6000 g
- Line-in
- Y
- Bus type
- DMI
- DVI port
- Y
- 64-bit support
- Y
1 / 6
Shopping actions
Overview
The Lenovo ThinkCentre Edge 72 Intel® Core™ i3 i3-3240 4 GB DDR3-SDRAM 500 GB HDD Windows 7 Professional SFF PC Black features Intel Core i3 processor, 2 cores, 4 GB of memory and DDR3-SDRAM. Full verified specifications are listed below.
Technical Specifications
Processor
12 SPECS
Cache
3 MB
Cores
2
Model
i3-3240
Processor line
Intel Core i3
Socket
LGA 1155 (Socket H2)
Threads
4
Clock speed
3.4 GHz
Cache level
Smart Cache
Process node
22 nm
CPU brand
Intel
CPU operating modes
64-bit
TDP
55 W
Storage
2 SPECS
Capacity
500 GB
Storage
500 GB
Graphics
1 SPEC
Memory clock
1600 MHz
Physical
6 SPECS
Depth
382 mm
Width
336 mm
Height
101 mm
Weight
6000 g
Product type
PC
Colour
Black
Memory
3 SPECS
Capacity
4 GB
Memory type
DDR3-SDRAM
Max memory
16 GB
Ports & Connectivity
3 SPECS
HDMI ports
0
USB 2.0 ports
6
Ethernet ports
1
General
110 SPECS
Max case temperature (Tcase)
65.3 °C
Line-in
Yes
Bus type
DMI
DVI port
Yes
64-bit support
Yes
Line-out
Yes
Spindle speed
7200 rpm
Audio chip
Realtek ALC662
FSB Parity
No
Idle power states
Yes
Audio system
High Definition Audio
Chassis type
SFF
Ethernet LAN
Yes
Memory slots
2x DIMM
Power supply
180
Drive interface
SATA II
Microphone input
Yes
Storage media
HDD
Security lock slot
Yes
Memory channels
Dual-channel
Bus speed
5 GT/s
Display included
No
Intel ARK ID
65690
Processor series
Intel Core i3-3200 Desktop series
Headphone outputs
1
Wake-on-LAN ready
Yes
Cabling technology
10/100/1000Base-T(X)
Intel® Insider™
Yes
Intel® Secure Key
No
Optical drive type
DVD±RW
Codename
Ivy Bridge
Execute Disable (NX)
Yes
Chipset
Intel H61
Number of 3.5" bays
1
Placement supported
Horizontal/Vertical
Cable lock slot type
Kensington
Intel FDI Technology
Yes
Number of 5.25" bays
1
Generation
Intel Core i3-3xxx
Card reader
Yes
Integrated graphics
Yes
Processor package size
37.5 x 37.5
CPU configuration (max)
1
Compliance certificates
RoHS
Conflict-free minerals
Yes
Ethernet LAN data rates
10,100,1000
Optical drives quantity
1
Intel Fast Memory Access
Yes
Intel Flex Memory Access
Yes
Number of HDDs installed
1
Intel Enhanced Halt State
Yes
On-board graphics card ID
0x152
PCI Express slots version
2.0
Recovery operating system
Windows 8 Pro
ECC memory support
Yes
Long-term availability
No
Operating system
Windows 7 Professional
PCI Express configurations
1x16,2x8
Instruction sets
AVX,SSE4.1,SSE4.2
VGA ports
1
Eco certifications
ENERGY STAR
Intel Clear Video Technology
No
Intel Demand Based Switching
No
Memory layout (slots x size)
1 x 4
Integrated GPU model
Intel HD Graphics 2500
Thunderbolt 3 ports quantity
0
On-board graphics card family
Intel HD Graphics
OS architecture
64-bit
Intel Rapid Storage Technology
No
Intel Smart Connect Technology
No
Intel® InTru™ 3D Technology
Yes
Intel® Rapid Start Technology
No
Intel® Turbo Boost Technology
No
Number of processors installed
1
PCI Express x1 (Gen 2.x) slots
2
Thermal solution specification
PCG 2011C
CPU multiplier (bus/core ratio)
34
PCI Express x16 (Gen 2.x) slots
1
Thermal monitoring
Yes
Intel® Smart Response Technology
No
Trusted Execution (TXT)
No
Number of storage drives installed
1
SpeedStep power scaling
Yes
Intel Secure Key Technology version
0.00
Intel® Quick Sync Video Technology
Yes
Memory types supported by processor
DDR3-SDRAM
Intel Dual Display Capable Technology
No
On-board graphics card base frequency
650
Virtualization (VT-x)
Yes
Intel® Wireless Display (Intel® WiDi)
Yes
Intel® My WiFi Technology (Intel® MWT)
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
Intel® Anti-Theft Technology (Intel® AT)
Yes
Memory clock speeds supported by processor
1333,1600
Intel Identity Protection Technology version
1.00
Intel® AES New Instructions (Intel® AES-NI)
No
Memory bandwidth supported by processor (max)
25.6
Intel® Small Business Advantage (Intel® SBA)
No
Maximum internal memory supported by processor
32
On-board graphics card dynamic frequency (max)
1050
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
Number of displays supported (on-board graphics)
3
Intel® Clear Video HD Technology (Intel® CVT HD)
Yes
Intel® Identity Protection Technology (Intel® IPT)
Yes
Directed I/O virtualization (VT-d)
No
Intel® Hyper Threading Technology (Intel® HT Technology)
Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
No
Market Value History
Price history not started yet
Daily price tracking begins as soon as this product is listed on Amazon US — the trend chart will appear here automatically.
Sources
Product lifecycle
In production
Still listed as on-market by the manufacturer — actively sold and supported.
Lifecycle status is derived from catalog data and is indicative, not a manufacturer support guarantee.
