MPN:
4V5H2
DELL Vostro 3268 Intel® Core™ i5 i5-7400 4 GB DDR4-SDRAM 1 TB HDD Windows 10 Pro SFF PC Black, Silver
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- Depth
- 314.5 mm
- Wi-Fi
- Y
- Width
- 92.6 mm
- Height
- 293.1 mm
- Manual included
- Y
- Weight
- 4400 g
- Line-in
- Y
- Bus type
- DMI3
- DVI port
- N
1 / 5
Shopping actions
Overview
The DELL Vostro 3268 Intel® Core™ i5 i5-7400 4 GB DDR4-SDRAM 1 TB HDD Windows 10 Pro SFF PC Black, Silver features Intel Core i5 processor, 4 cores, up to 3.5 GHz boost and 4 GB of memory. Full verified specifications are listed below.
Technical Specifications
Processor
14 SPECS
Stepping
B0
Cache
6 MB
Cores
4
Model
i5-7400
Processor line
Intel Core i5
Socket
LGA 1151 (Socket H4)
Threads
4
Clock speed
3 GHz
Cache level
Smart Cache
Process node
14 nm
CPU brand
Intel
Boost clock
3.5 GHz
CPU operating modes
64-bit
TDP
65 W
Storage
2 SPECS
Capacity
1 TB
Storage
1 TB
Physical
7 SPECS
Depth
314.5 mm
Width
92.6 mm
Height
293.1 mm
Weight
4400 g
Product type
PC
Colour
Black,Silver
Market segment
Business
Memory
3 SPECS
Capacity
4 GB
Memory type
DDR4-SDRAM
Max memory
16 GB
Ports & Connectivity
3 SPECS
HDMI ports
1
USB 2.0 ports
4
Ethernet ports
1
Graphics
1 SPEC
Memory clock
2400 MHz
General
124 SPECS
Wi-Fi
Yes
Manual included
Yes
Line-in
Yes
Bus type
DMI3
DVI port
No
Drive form factor
3.5
64-bit support
Yes
Line-out
Yes
Bluetooth
Yes
Spindle speed
7200 rpm
Tjunction
100
Idle power states
Yes
Scalability
1S
Audio system
High Definition Audio
Chassis type
SFF
Ethernet LAN
Yes
Intel TSX-NI
No
Memory slots
2x DIMM
Power supply
65
Drive interface
SATA III
Microphone input
Yes
Storage media
HDD
Processor code
SR32W
Trial software
Microsoft Office, McAfee
Included cables
AC
Memory channels
Dual-channel
Bus speed
8 GT/s
Wi-Fi standard
802.11b,802.11g,Wi-Fi 4 (802.11n)
Display included
No
Intel® OS Guard
Yes
Intel ARK ID
97147
Processor series
Intel Core i5-7400 Desktop Series
Bluetooth version
4.0
Headphone outputs
1
Cabling technology
10/100/1000Base-T(X)
Intel® Secure Key
Yes
Operating altitude
-15.2 - 5000
Optical drive type
DVD±RW
Codename
Kaby Lake
Top Wi-Fi standard
Wi-Fi 4 (802.11n)
Execute Disable (NX)
Yes
Chipset
Intel H110
Number of 3.5" bays
1
Number of QPI links
0
Placement supported
Vertical
Intel TSX-NI version
0.00
Number of 5.25" bays
1
PCI Express x1 slots
1
Generation
Intel Core i5-7xxx
Audio channels
5.1
PCI Express x16 slots
1
Card reader
Yes
Dedicated graphics
No
Non-operating altitude
-15.2 - 10668
Integrated graphics
Yes
Processor package size
37.5 x 37.5
CPU configuration (max)
1
Conflict-free minerals
Yes
Ethernet LAN data rates
10,100,1000
Optical drives quantity
1
Number of HDDs installed
1
Intel Enhanced Halt State
Yes
On-board graphics card ID
5912
Operating system language
Multilingual
PCI Express slots version
3.0
Storage temperature
-40 - 65
Bluetooth Low Energy (BLE)
Yes
ECC memory support
No
Long-term availability
No
Operating system
Windows 10 Pro
PCI Express configurations
1x16,1x8+2x4,2x8
Power supply input voltage
100 - 240
Instruction sets
AVX 2.0,SSE4.1,SSE4.2
VGA ports
1
Compatible processor series
Intel Celeron,Intel Pentium
Operating temperature
10 - 35
Dedicated GPU model
Not available
Intel Clear Video Technology
Yes
Memory layout (slots x size)
1 x 4
Integrated GPU model
Intel HD Graphics 630
Power supply input frequency
50 - 60
Thunderbolt 3 ports quantity
0
On-board graphics card family
Intel HD Graphics
OS architecture
64-bit
Intel® InTru™ 3D Technology
Yes
Intel® Turbo Boost Technology
2.0
Number of processors installed
1
Thermal solution specification
PCG 2015C
Thermal monitoring
Yes
Operating humidity
20 - 80
Trusted Execution (TXT)
No
Number of storage drives installed
1
SpeedStep power scaling
Yes
Intel Secure Key Technology version
1.00
Intel® Quick Sync Video Technology
Yes
PCIe lanes
16
Memory types supported by processor
DDR3L-SDRAM,DDR4-SDRAM
Maximum on-board graphics card memory
64
Memory voltage supported by processor
1.35
On-board graphics card OpenGL version
4.4
On-board graphics card base frequency
350
Virtualization (VT-x)
Yes
On-board graphics card DirectX version
12.0
Mouse included on selected markets only
Yes
Intel Stable Image Platform Program (SIPP)
No
Intel VT-x with Extended Page Tables (EPT)
Yes
Keyboard included on selected markets only
Yes
Memory clock speeds supported by processor
1333,1600,2133,2400
Intel Software Guard Extensions (Intel SGX)
Yes
Intel Identity Protection Technology version
1.00
Intel® AES New Instructions (Intel® AES-NI)
Yes
Maximum internal memory supported by processor
64
On-board graphics card dynamic frequency (max)
1000
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
Number of displays supported (on-board graphics)
3
Intel Stable Image Platform Program (SIPP) version
0.00
Intel® Clear Video HD Technology (Intel® CVT HD)
Yes
Intel® Identity Protection Technology (Intel® IPT)
Yes
Directed I/O virtualization (VT-d)
Yes
Intel® Hyper Threading Technology (Intel® HT Technology)
No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
Yes
