MPN:
YHVV1
DELL Pro Max FCS1250 Intel Core Ultra 5 235 16 GB DDR5-SDRAM 512 GB SSD Windows 11 Pro Slim PC PC Black
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- NVMe
- Y
- Depth
- 293 mm
- Wi-Fi
- N
- Width
- 95 mm
- Height
- 303.5 mm
- Weight
- 6110 g
- Non-ECC
- Y
- Audio chip
- Realtek ALC3204
- DC-in jack
- Y
1 / 6
Shopping actions
Overview
Versatile desktop that delivers powerful and reliable performance in a small size.
Technical Specifications
Processor
8 SPECS
Cache
24 MB
Cores
14
Model
235
Processor line
Intel Core Ultra 5
Threads
14
Cache level
Smart Cache
CPU brand
Intel
Boost clock
5 GHz
Storage
3 SPECS
Capacity
512 GB
Form factor
M.2
Storage
512 GB
Physical
7 SPECS
Depth
293 mm
Width
95 mm
Height
303.5 mm
Weight
6110 g
Product type
PC
Colour
Black
Market segment
Business
Memory
3 SPECS
Capacity
16 GB
Memory type
DDR5-SDRAM
Max memory
128 GB
Ports & Connectivity
3 SPECS
DisplayPorts quantity
3
USB 2.0 ports
4
Ethernet ports
1
General
82 SPECS
NVMe
Yes
Wi-Fi
No
Non-ECC
Yes
Audio chip
Realtek ALC3204
DC-in jack
Yes
Audio system
High Definition Audio
Chassis type
Slim PC
Ethernet LAN
Yes
M.2 SSD size
2280 (22 x 80 mm)
Memory slots
4x DIMM
Power supply
360
SSD interface
PCI Express
Storage media
SSD
LAN controller
Intel I219-LM
Security lock slot
Yes
Included cables
AC
Doesn't contain
PVC/BFR
Efficient cores
8
Operating shock resistance
110
SSD memory type
TLC
Wi-Fi standard
802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6E (802.11ax),Wi-Fi 7 (802.11be)
Display included
No
Sparsity support
Yes
Performance cores
6
Cabling technology
10/100/1000Base-T(X)
Operating altitude
-15.2 - 3048
Optical drive type
DVD±RW
DisplayPort version
1.4a
Maximum turbo power
121
Non-operating shock resistance
160
Operating vibration tolerance
0.66
Placement supported
Horizontal/Vertical
Total SSDs capacity
512
Cable lock slot type
Kensington
Processor base power
65
Generation
Intel Core Ultra (Series 2)
GPU performance up to
6
NPU performance up to
13
Dedicated graphics
No
Non-operating altitude
-15.2 - 10668
Integrated graphics
Yes
Ethernet LAN data rates
10,100,1000
Non-operating vibration tolerance
1.3
Combo headphone/mic port
Yes
Number of SSDs installed
1
Number of rear USB ports
6
Number of front USB ports
4
On-board GPU manufacturer
Intel
Storage temperature
-40 - 65
Operating system
Windows 11 Pro
Power supply input voltage
90 - 264
Neural processor unit (NPU)
Intel AI Boost
Operating temperature
0 - 35
Eco certifications
ENERGY STAR,EPEAT Climate +
Dedicated GPU model
Not available
Integrated GPU model
Intel Graphics
Power supply input frequency
47/63
Efficient-core base frequency
2.9
Number of SATA III connectors
2
On-board graphics card family
Intel Graphics
OS architecture
64-bit
Trusted Platform Module (TPM)
Yes
Number of processors installed
1
PCI Express x1 (Gen 3.x) slots
1
PCI Express x4 (Gen 3.x) slots
1
Windows Studio effects support
Yes
PCI Express x16 (Gen 4.x) slots
1
Performance-core base frequency
3.4
Storage relative humidity (H-H)
0 - 95
Operating humidity
10 - 90
Total processor performance up to
27
Efficient-core Max Turbo Frequency
4.4
Number of storage drives installed
1
Performance-core Max Turbo Frequency
5
Trusted Platform Module (TPM) version
2.0
USB 3.2 Gen 2x2 Type-C ports quantity
1
AI software frameworks supported by NPU
DirectML,OpenVINO,Windows ML,ONNX RT,WebNN
Graphics card Mini DisplayPort ports quantity
4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
1
