MPN:
N016O7050MFFAU + P2417H
DELL OptiPlex 7050m Intel® Core™ i7 i7-7700T 8 GB DDR4-SDRAM 256 GB SSD Windows 10 Pro Mini PC Black
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- Depth
- 178 mm
- Wi-Fi
- N
- Width
- 36 mm
- Height
- 182 mm
- Manual included
- Y
- Volume
- 1.2
- Weight
- 1180 g
- Full HD
- Y
- Bus type
- DMI3
1 / 5
Shopping actions
Overview
The DELL OptiPlex 7050m Intel® Core™ i7 i7-7700T 8 GB DDR4-SDRAM 256 GB SSD Windows 10 Pro Mini PC Black features Intel Core i7 processor, 4 cores, up to 3.8 GHz boost and 8 GB of memory. Full verified specifications are listed below.
Technical Specifications
Processor
14 SPECS
Stepping
B0
Cache
8 MB
Cores
4
Model
i7-7700T
Processor line
Intel Core i7
Socket
LGA 1151 (Socket H4)
Threads
8
Clock speed
2.9 GHz
Cache level
Smart Cache
Process node
14 nm
CPU brand
Intel
Boost clock
3.8 GHz
CPU operating modes
64-bit
TDP
35 W
Memory
3 SPECS
Capacity
8 GB
Memory type
DDR4-SDRAM
Max memory
32 GB
Storage
2 SPECS
Capacity
256 GB
Storage
256 GB
Display
8 SPECS
Panel type
IPS
Touchscreen
No
Screen size
23.8"
Resolution
1920 x 1080
Aspect ratio
16:9
Vertical viewing angle
178°
Contrast ratio
1000:1
Horizontal viewing angle
178°
Physical
6 SPECS
Depth
178 mm
Width
36 mm
Height
182 mm
Weight
1180 g
Product type
Mini PC (<= 3L)
Colour
Black
Ports & Connectivity
3 SPECS
HDMI ports
1
USB 2.0 ports
0
Ethernet ports
1
Graphics
1 SPEC
Memory clock
2400 MHz
General
116 SPECS
Wi-Fi
No
Manual included
Yes
Volume
1.2
Full HD
Yes
Bus type
DMI3
DVI port
No
64-bit support
Yes
Tjunction
80
Audio chip
Realtek ALC3234
Idle power states
Yes
Scalability
1S
Chassis type
Mini PC
Display type
LED
Ethernet LAN
Yes
Intel TSX-NI
Yes
Memory slots
2x SO-DIMM
Power supply
65
Microphone input
Yes
SSD interface
PCI Express
Storage media
SSD
Mouse included
Yes
Processor code
SR339
Included cables
AC
Memory channels
Dual-channel
Bus speed
8 GT/s
Display included
Yes
Drivers included
Yes
Intel® OS Guard
Yes
Intel ARK ID
97122
Processor series
Intel Core i7-7700 Desktop Series
Headphone outputs
1
Keyboard included
Yes
Cabling technology
10/100/1000Base-T(X)
Display brightness
250
Intel® Secure Key
Yes
Operating altitude
-15.2 - 3048
Optical drive type
No
Codename
Kaby Lake
AC adapter included
Yes
Execute Disable (NX)
Yes
Number of QPI links
0
Password protection
Yes
Placement supported
Horizontal/Vertical
Intel TSX-NI version
1.00
Generation
Intel Core i7-7xxx
Configurable TDP-down
25
Card reader
Yes
Dedicated graphics
No
Non-operating altitude
-15.2 - 10668
Integrated graphics
Yes
Processor package size
37.5 x 37.5
CPU configuration (max)
1
Conflict-free minerals
Yes
Ethernet LAN data rates
10,100,1000
Number of SSDs installed
1
Password protection type
BIOS,Supervisor
Display number of colours
16.78 million colours
Intel Enhanced Halt State
Yes
On-board graphics card ID
5912
PCI Express slots version
3.0
Storage temperature
-40 - 65
ECC memory support
No
Long-term availability
Yes
Operating system
Windows 10 Pro
PCI Express configurations
1x16,1x8+2x4,2x8
Power supply input voltage
90 - 264
Instruction sets
AVX 2.0,SSE4.1,SSE4.2
Operating temperature
0 - 35
Dedicated GPU model
Not available
Intel Clear Video Technology
Yes
Memory layout (slots x size)
1 x 8
Integrated GPU model
Intel HD Graphics 630
Power supply input frequency
47/63
Thunderbolt 3 ports quantity
0
OS architecture
64-bit
Trusted Platform Module (TPM)
Yes
Intel® InTru™ 3D Technology
Yes
Intel® Turbo Boost Technology
2.0
Number of processors installed
1
Thermal solution specification
PCG 2015A
Configurable TDP-down frequency
1.9
Storage relative humidity (H-H)
5 - 95
Thermal monitoring
Yes
Operating humidity
10 - 90
Trusted Execution (TXT)
Yes
Number of storage drives installed
1
SpeedStep power scaling
Yes
Intel Secure Key Technology version
1.00
Intel® Quick Sync Video Technology
Yes
PCIe lanes
16
Memory types supported by processor
DDR3L-SDRAM,DDR4-SDRAM
Maximum on-board graphics card memory
64
Memory voltage supported by processor
1.35
On-board graphics card OpenGL version
4.4
On-board graphics card base frequency
350
Virtualization (VT-x)
Yes
On-board graphics card DirectX version
12.0
Intel Stable Image Platform Program (SIPP)
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
Memory clock speeds supported by processor
1333,1600,2133,2400
Intel Software Guard Extensions (Intel SGX)
Yes
Intel Identity Protection Technology version
1.00
Intel® AES New Instructions (Intel® AES-NI)
Yes
Maximum internal memory supported by processor
64
On-board graphics card dynamic frequency (max)
1150
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
5
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
Number of displays supported (on-board graphics)
3
Intel Stable Image Platform Program (SIPP) version
1.00
Intel® Clear Video HD Technology (Intel® CVT HD)
Yes
Intel® Identity Protection Technology (Intel® IPT)
Yes
Directed I/O virtualization (VT-d)
Yes
Intel® Hyper Threading Technology (Intel® HT Technology)
Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
Yes
