MPN:
N020O7050MFF02
DELL OptiPlex 7050 Intel® Core™ i5 i5-7500T 8 GB DDR4-SDRAM 256 GB SSD Windows 10 Pro Mini PC Black
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- Depth
- 177.8 mm
- Wi-Fi
- N
- Width
- 35.56 mm
- Height
- 182.88 mm
- Manual included
- Y
- Volume
- 1.2
- Weight
- 1180 g
- Non-ECC
- Y
- Bus type
- DMI3
1 / 6
Shopping actions
Overview
The DELL OptiPlex 7050 Intel® Core™ i5 i5-7500T 8 GB DDR4-SDRAM 256 GB SSD Windows 10 Pro Mini PC Black features Intel Core i5 processor, 4 cores, up to 3.3 GHz boost and 8 GB of memory. Full verified specifications are listed below.
Technical Specifications
Processor
13 SPECS
Cache
6 MB
Cores
4
Model
i5-7500T
Processor line
Intel Core i5
Socket
LGA 1151 (Socket H4)
Threads
4
Clock speed
2.7 GHz
Cache level
Smart Cache
Process node
14 nm
CPU brand
Intel
Boost clock
3.3 GHz
CPU operating modes
64-bit
TDP
35 W
Storage
2 SPECS
Capacity
256 GB
Storage
256 GB
Graphics
1 SPEC
Memory clock
2400 MHz
Physical
6 SPECS
Depth
177.8 mm
Width
35.56 mm
Height
182.88 mm
Weight
1180 g
Product type
Mini PC (<= 3L)
Colour
Black
Ports & Connectivity
4 SPECS
HDMI ports
1
DisplayPorts quantity
1
USB 2.0 ports
0
Ethernet ports
1
Memory
3 SPECS
Capacity
8 GB
Memory type
DDR4-SDRAM
Max memory
32 GB
General
121 SPECS
Wi-Fi
No
Manual included
Yes
Volume
1.2
Non-ECC
Yes
Bus type
DMI3
DVI port
No
64-bit support
Yes
Line-out
Yes
Tjunction
80
Audio chip
Realtek ALC3234
DC-in jack
Yes
PowerShare
Yes
Idle power states
Yes
Scalability
1S
Chassis type
Mini PC
Ethernet LAN
Yes
Intel TSX-NI
Yes
Memory slots
2x SO-DIMM
Power supply
65
Microphone input
No
SSD interface
SATA III
Storage media
SSD
Trial software
Microsoft Office, McAfee Small Business Security
Security lock slot
Yes
Included cables
AC
Memory channels
Dual-channel
Bus speed
8 GT/s
Display included
No
Intel® OS Guard
Yes
Intel ARK ID
97121
Headphone outputs
1
Cabling technology
10/100/1000Base-T(X)
Intel® Secure Key
Yes
Operating altitude
-15.2 - 3048
Optical drive type
No
Codename
Kaby Lake
AC adapter included
Yes
Execute Disable (NX)
Yes
Number of 2.5" bays
1
Number of QPI links
0
Password protection
Yes
Placement supported
Horizontal/Vertical
Power cord included
Yes
Intel TSX-NI version
1.00
Generation
Intel Core i5-7xxx
Card reader
No
Dedicated graphics
No
Non-operating altitude
-15.2 - 10668
Integrated graphics
Yes
Processor package size
37.5 x 37.5
CPU configuration (max)
1
Conflict-free minerals
Yes
Ethernet LAN data rates
10,100,1000
Combo headphone/mic port
Yes
Number of SSDs installed
1
Password protection type
BIOS,Supervisor,User
Intel Enhanced Halt State
Yes
On-board graphics card ID
0x5912
Operating system language
DEU,DUT,ENG,FRE,ITA
PCI Express slots version
3.0
Storage temperature
-40 - 65
ECC memory support
No
Long-term availability
Yes
Operating system
Windows 10 Pro
PCI Express configurations
2x8,1x8+2x4
Power supply input voltage
90 - 264
Instruction sets
AVX 2.0
Thunderbolt ports quantity
0
VGA ports
0
Compatible processor series
Intel Core i3,Intel Core i5,Intel Core i7
Operating temperature
0 - 35
Dedicated GPU model
Not available
Intel Clear Video Technology
Yes
Memory layout (slots x size)
1 x 8
Integrated GPU model
Intel HD Graphics 630
Power supply input frequency
47 - 63
Thunderbolt 3 ports quantity
0
On-board graphics card family
Intel HD Graphics
OS architecture
64-bit
Intel® InTru™ 3D Technology
Yes
Intel® Turbo Boost Technology
2.0
Number of processors installed
1
Thermal solution specification
PCG 2015A
Configurable TDP-down frequency
1.7
Storage relative humidity (H-H)
5 - 95
Thermal monitoring
Yes
Operating humidity
10 - 90
Trusted Execution (TXT)
Yes
SpeedStep power scaling
Yes
Intel Secure Key Technology version
1.00
Intel® Quick Sync Video Technology
Yes
PCIe lanes
16
Memory types supported by processor
DDR3L-SDRAM,DDR4-SDRAM
Maximum on-board graphics card memory
64
Memory voltage supported by processor
1.35
On-board graphics card OpenGL version
4.4
On-board graphics card base frequency
350
Virtualization (VT-x)
Yes
On-board graphics card DirectX version
12.0
Mouse included on selected markets only
Yes
Intel Stable Image Platform Program (SIPP)
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
Keyboard included on selected markets only
Yes
Memory clock speeds supported by processor
1333,1600,2133,2400
Intel Software Guard Extensions (Intel SGX)
Yes
Number of USB ports with PowerShare support
1
Intel Identity Protection Technology version
1.00
Intel® AES New Instructions (Intel® AES-NI)
Yes
Maximum internal memory supported by processor
64
On-board graphics card dynamic frequency (max)
1100
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
5
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
Number of displays supported (on-board graphics)
3
Intel Stable Image Platform Program (SIPP) version
1.00
Intel® Clear Video HD Technology (Intel® CVT HD)
Yes
Intel® Identity Protection Technology (Intel® IPT)
Yes
Directed I/O virtualization (VT-d)
Yes
Intel® Hyper Threading Technology (Intel® HT Technology)
No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
Yes
