MPN:
90MS00L2-M00040
ASUS VivoMini UN45-D-M004Z Intel® Celeron® N3000 2 GB DDR3L-SDRAM 32 GB SSD Windows 10 Desktop Mini PC Blue
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- UART
- Y
- Depth
- 131 mm
- Wi-Fi
- Y
- Width
- 131 mm
- Height
- 42 mm
- DVI port
- N
- 64-bit support
- Y
- Stepping
- C0
- Bluetooth
- Y
1 / 6
Shopping actions
Overview
The ASUS VivoMini UN45-D-M004Z Intel® Celeron® N3000 2 GB DDR3L-SDRAM 32 GB SSD Windows 10 Desktop Mini PC Blue features Intel Celeron processor, 2 cores, up to 2.08 GHz boost and 2 GB of memory. Full verified specifications are listed below.
Technical Specifications
Processor
14 SPECS
Stepping
C0
Cache
2 MB
Cores
2
Model
N3000
Processor line
Intel Celeron
Socket
BGA 1170
Threads
2
Clock speed
1.04 GHz
Cache level
L2
Process node
14 nm
CPU brand
Intel
Boost clock
2.08 GHz
CPU operating modes
64-bit
TDP
4 W
Storage
2 SPECS
Capacity
32 GB
Storage
32 GB
Ports & Connectivity
5 SPECS
HDMI ports
1
PS/2 ports
0
DisplayPorts quantity
0
USB 2.0 ports
0
Ethernet ports
1
Physical
5 SPECS
Depth
131 mm
Width
131 mm
Height
42 mm
Product type
Mini PC (<= 3L)
Colour
Blue
Memory
3 SPECS
Capacity
2 GB
Memory type
DDR3L-SDRAM
Max memory
8 GB
Graphics
1 SPEC
Memory clock
1600 MHz
General
107 SPECS
UART
Yes
Wi-Fi
Yes
DVI port
No
64-bit support
Yes
Bluetooth
Yes
Tjunction
90
DC-in jack
Yes
Idle power states
Yes
Chassis type
Desktop
Ethernet LAN
Yes
Memory slots
2x SO-DIMM
Certifications
BSMI/CE/FCC/UL/CCC/WiFi/VCCI
Microphone input
No
SSD interface
M.2
Storage media
SSD
VESA mounting
Yes
Processor code
SR29J
Security lock slot
Yes
Memory channels
Dual-channel
Wi-Fi standard
802.11a,Wi-Fi 5 (802.11ac),802.11b,802.11g,Wi-Fi 4 (802.11n)
Display included
No
Intel® OS Guard
No
Intel ARK ID
87259
Processor series
Intel Celeron N3000 series
Bluetooth version
4.0
Headphone outputs
0
Intel Secure Boot
Yes
Cabling technology
10/100/1000Base-T(X)
Intel® Insider™
No
Intel® Secure Key
Yes
Optical drive type
No
Codename
Braswell
Top Wi-Fi standard
Wi-Fi 5 (802.11ac)
Execute Disable (NX)
Yes
Integrated 4G WiMAX
No
Cable lock slot type
Kensington
Card reader
No
Integrated graphics
Yes
Processor package size
25 x 27
CPU configuration (max)
1
Conflict-free minerals
Yes
Ethernet LAN data rates
10,100,1000
Combo headphone/mic port
Yes
Mini HDMI ports quantity
0
Number of SSDs installed
1
Intel Enhanced Halt State
Yes
Number of execution units
12
PCI Express slots version
2.0
ECC memory support
No
Long-term availability
No
Operating system
Windows 10
PCI Express configurations
1x4,4x1
Thunderbolt ports quantity
0
Scenario Design Power (SDP)
3
Eco certifications
ENERGY STAR
Dedicated GPU model
Not available
Intel Clear Video Technology
Yes
Memory layout (slots x size)
1 x 2
Integrated GPU model
Intel HD Graphics
Thunderbolt 2 ports quantity
0
Thunderbolt 3 ports quantity
0
Number of SATA III connectors
2
On-board graphics card family
Intel HD Graphics
Intel Rapid Storage Technology
No
Intel Smart Connect Technology
No
Intel® InTru™ 3D Technology
No
Intel® Turbo Boost Technology
No
Number of processors installed
1
Thermal monitoring
Yes
Total number of SATA connectors
2
Intel® Smart Response Technology
No
Trusted Execution (TXT)
No
SpeedStep power scaling
Yes
Intel Secure Key Technology version
1.00
Intel® Quick Sync Video Technology
Yes
PCIe lanes
4
Memory types supported by processor
DDR3L-SDRAM
Intel Secure Boot Technology version
1.00
Maximum on-board graphics card memory
8
On-board graphics card base frequency
320
Intel Smart Connect Technology version
0.00
Virtualization (VT-x)
Yes
On-board graphics card DirectX version
Yes
On-board graphics card burst frequency
600
Intel Smart Response Technology version
0.00
Intel® Wireless Display (Intel® WiDi)
Yes
Intel Stable Image Platform Program (SIPP)
No
Intel VT-x with Extended Page Tables (EPT)
Yes
Intel® Anti-Theft Technology (Intel® AT)
No
Memory clock speeds supported by processor
1600
Intel Identity Protection Technology version
1.00
Intel Small Business Advantage (SBA) version
0.00
Intel® AES New Instructions (Intel® AES-NI)
Yes
Intel® Small Business Advantage (Intel® SBA)
No
Maximum internal memory supported by processor
8
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
Intel® High Definition Audio (Intel® HD Audio)
Yes
Number of displays supported (on-board graphics)
3
Intel Stable Image Platform Program (SIPP) version
0.00
Intel® Clear Video HD Technology (Intel® CVT HD)
Yes
Intel® Identity Protection Technology (Intel® IPT)
Yes
Directed I/O virtualization (VT-d)
No
Intel® Hyper Threading Technology (Intel® HT Technology)
No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
Yes
Market Value History
Price history not started yet
Daily price tracking begins as soon as this product is listed on Amazon US — the trend chart will appear here automatically.
Sources
Product lifecycle
In production
Still listed as on-market by the manufacturer — actively sold and supported.
Lifecycle status is derived from catalog data and is indicative, not a manufacturer support guarantee.
