MPN:
E410-B0105
ASUS E410-B0105 PC/workstation Intel® Celeron® N3150 2 GB DDR3L-SDRAM 32 GB SSD Windows 10 Home Mini PC Black
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- UART
- Y
- Depth
- 172.5 mm
- Wi-Fi
- Y
- Width
- 219 mm
- Height
- 29 mm
- Manual included
- Y
- Volume
- 1.1
- Weight
- 690 g
- DVI port
- N
1 / 4
Shopping actions
Overview
The ASUS E410-B0105 PC/workstation Intel® Celeron® N3150 2 GB DDR3L-SDRAM 32 GB SSD Windows 10 Home Mini PC Black features Intel Celeron processor, 4 cores, up to 2.08 GHz boost and 2 GB of memory. Full verified specifications are listed below.
Technical Specifications
Processor
14 SPECS
Stepping
C0
Cache
2 MB
Cores
4
Model
N3150
Processor line
Intel Celeron
Socket
BGA 1170
Threads
4
Clock speed
1.6 GHz
Cache level
Smart Cache
Process node
14 nm
CPU brand
Intel
Boost clock
2.08 GHz
CPU operating modes
64-bit
TDP
6 W
Storage
2 SPECS
Capacity
32 GB
Storage
32 GB
Physical
6 SPECS
Depth
172.5 mm
Width
219 mm
Height
29 mm
Weight
690 g
Product type
Mini PC (<= 3L)
Colour
Black
Memory
3 SPECS
Capacity
2 GB
Memory type
DDR3L-SDRAM
Max memory
8 GB
Ports & Connectivity
3 SPECS
HDMI ports
1
USB 2.0 ports
2
Ethernet ports
1
Graphics
1 SPEC
Memory clock
1600 MHz
General
101 SPECS
UART
Yes
Wi-Fi
Yes
Manual included
Yes
Volume
1.1
DVI port
No
64-bit support
Yes
Tjunction
90
DC-in jack
Yes
Idle power states
Yes
Chassis type
Mini PC
Ethernet LAN
Yes
Memory slots
1x SO-DIMM
Power supply
45
Certifications
BSMI/CB/CE/FCC/UL/CCC/Energy Star/CECP/C-Tick/WiFi/RF/CSA
Microphone input
Yes
Storage media
SSD
Processor code
SR29F
Memory channels
Dual-channel
Bus speed
5 GT/s
Wi-Fi standard
802.11b,802.11g,Wi-Fi 4 (802.11n)
Display included
No
Intel® OS Guard
No
Intel ARK ID
87258
Processor series
Intel Celeron N3000 series
Headphone outputs
1
Intel Secure Boot
Yes
Intel® Insider™
No
Intel® Secure Key
Yes
Optical drive type
No
Codename
Braswell
Top Wi-Fi standard
Wi-Fi 4 (802.11n)
AC adapter included
Yes
Execute Disable (NX)
Yes
Integrated 4G WiMAX
No
Serial ports
1
Card reader
Yes
Integrated graphics
Yes
Processor package size
25 x 27
CPU configuration (max)
1
Conflict-free minerals
Yes
Ethernet LAN data rates
10,100,1000
Optical drives quantity
0
Number of SSDs installed
1
Intel Enhanced Halt State
Yes
Number of execution units
12
PCI Express slots version
2.0
ECC memory support
No
Long-term availability
No
Operating system
Windows 10 Home
PCI Express configurations
1x4,4x1
VGA ports
1
Scenario Design Power (SDP)
4
Eco certifications
ENERGY STAR
Intel Clear Video Technology
Yes
Integrated GPU model
Intel HD Graphics
Number of SATA III connectors
2
On-board graphics card family
Intel HD Graphics
Intel Rapid Storage Technology
No
Intel Smart Connect Technology
No
Intel® InTru™ 3D Technology
No
Intel® Turbo Boost Technology
No
Number of processors installed
1
Thermal monitoring
Yes
Total number of SATA connectors
2
Intel® Smart Response Technology
No
Trusted Execution (TXT)
No
SpeedStep power scaling
Yes
Intel Secure Key Technology version
1.00
Intel® Quick Sync Video Technology
Yes
PCIe lanes
4
Memory types supported by processor
DDR3L-SDRAM
Intel Secure Boot Technology version
1.00
Maximum on-board graphics card memory
8
On-board graphics card base frequency
320
Intel Smart Connect Technology version
0.00
Virtualization (VT-x)
Yes
On-board graphics card DirectX version
Yes
On-board graphics card burst frequency
640
Intel Smart Response Technology version
0.00
Intel® Wireless Display (Intel® WiDi)
Yes
Intel Stable Image Platform Program (SIPP)
No
Intel VT-x with Extended Page Tables (EPT)
Yes
Intel® Anti-Theft Technology (Intel® AT)
No
Memory clock speeds supported by processor
1600
Intel Identity Protection Technology version
1.00
Intel Small Business Advantage (SBA) version
0.00
Intel® AES New Instructions (Intel® AES-NI)
Yes
Intel® Small Business Advantage (Intel® SBA)
No
Maximum internal memory supported by processor
8
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
Intel® High Definition Audio (Intel® HD Audio)
Yes
Number of displays supported (on-board graphics)
3
Intel Stable Image Platform Program (SIPP) version
0.00
Intel® Clear Video HD Technology (Intel® CVT HD)
Yes
Intel® Identity Protection Technology (Intel® IPT)
Yes
Directed I/O virtualization (VT-d)
No
Intel® Hyper Threading Technology (Intel® HT Technology)
No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
Yes
