MPN:
AREA51R-6838S
Alienware Area-51 R4 Intel® Core™ i7 X-series i7-7820X 16 GB DDR4-SDRAM 2.25 TB HDD+SSD NVIDIA® GeForce® GTX 1080 Windows 10 Home Tower PC Black, Grey, Silver
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- CUDA
- Y
- Depth
- 272.71 mm
- Width
- 638.98 mm
- Height
- 569.98 mm
- Manual included
- Y
- Line-in
- Y
- Bus type
- DMI3
- DVI port
- N
- Drive form factor
- 3.5
1 / 9
Shopping actions
Overview
The Alienware Area-51 R4 Intel® Core™ i7 X-series i7-7820X 16 GB DDR4-SDRAM 2.25 TB HDD+SSD NVIDIA® GeForce® GTX 1080 Windows 10 Home Tower PC Black, Grey, Silver features Intel Core i7 X-series processor, 8 cores, up to 4.3 GHz boost and 8 GB of video memory. Full verified specifications are listed below.
Technical Specifications
Processor
14 SPECS
Stepping
U0
Cache
11 MB
Cores
8
Model
i7-7820X
Processor line
Intel Core i7 X-series
Socket
LGA 2066 (Socket R4)
Threads
16
Clock speed
3.6 GHz
Cache level
L3
Process node
14 nm
CPU brand
Intel
Boost clock
4.3 GHz
CPU operating modes
64-bit
TDP
140 W
Storage
3 SPECS
Capacity
2 TB
Capacity
256 GB
Storage
2256 GB
Physical
6 SPECS
Depth
272.71 mm
Width
638.98 mm
Height
569.98 mm
Product type
PC
Colour
Black,Grey,Silver
Market segment
Gaming
Graphics
3 SPECS
CUDA
Yes
CUDA cores
2560
VRAM
8 GB
Memory
3 SPECS
Capacity
16 GB
Memory type
DDR4-SDRAM
Max memory
64 GB
Ports & Connectivity
3 SPECS
HDMI ports
0
USB 2.0 ports
2
Ethernet ports
2
General
89 SPECS
Manual included
Yes
Line-in
Yes
Bus type
DMI3
DVI port
No
Drive form factor
3.5
64-bit support
Yes
Line-out
Yes
Spindle speed
7200 rpm
Tjunction
99
Audio chip
Realtek ALC3861
Scalability
1S
Audio system
High Definition Audio
Chassis type
Tower
Ethernet LAN
Yes
Memory slots
4x DIMM
Microphone input
Yes
NVIDIA G-SYNC
Yes
Storage media
HDD+SSD
Processor code
SR3L5
Included cables
AC
Memory channels
Quad-channel
S/PDIF out port
Yes
Bus speed
8 GT/s
Wi-Fi standard
Wi-Fi 5 (802.11ac)
Display included
No
Drivers included
Yes
Intel ARK ID
123767
Headphone outputs
1
Cabling technology
10/100/1000Base-T(X)
Operating altitude
-15.24 - 3048
Optical drive type
DVD Super Multi
Codename
Skylake
Top Wi-Fi standard
Wi-Fi 5 (802.11ac)
Execute Disable (NX)
Yes
NVIDIA GameWorks VR
Yes
Number of 2.5" bays
2
Number of 3.5" bays
3
Number of QPI links
0
Password protection
Yes
Placement supported
Vertical
Number of 5.25" bays
1
Generation
Intel Core i7-7xxx
Audio channels
7.1
Card reader
Yes
Dedicated graphics
Yes
Non-operating altitude
-15.24 - 10668
CPU configuration (max)
1
Conflict-free minerals
Yes
Ethernet LAN data rates
10,100,1000
Optical drives quantity
1
Number of HDDs installed
1
Number of SSDs installed
1
PCI Express slots version
3.0
Storage temperature
-40 - 65
ECC memory support
No
Long-term availability
No
Operating system
Windows 10 Home
Instruction sets
AVX 2.0,AVX-512,SSE4.1,SSE4.2
VGA ports
0
Virtual Reality (VR) ready
Yes
Compatible processor series
Intel Core i9
Operating temperature
5 - 35
Dedicated GPU model
NVIDIA GeForce GTX 1080
Power supply input frequency
50 - 60
Thunderbolt 3 ports quantity
0
Discrete graphics memory type
GDDR5X
OS architecture
64-bit
Intel® Turbo Boost Technology
2.0
Thermal solution specification
PCG 2017X
Storage relative humidity (H-H)
0 - 95
Graphics card HDMI ports quantity
1
Number of discrete graphics cards
1
Operating humidity
10 - 90
Graphics card DVI-D ports quantity
1
Number of storage drives installed
2
SpeedStep power scaling
Yes
Graphics card DisplayPorts quantity
3
PCIe lanes
28
Memory types supported by processor
DDR4-SDRAM
Virtualization (VT-x)
Yes
Memory clock speeds supported by processor
2666
Intel® AES New Instructions (Intel® AES-NI)
Yes
Maximum internal memory supported by processor
128
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
8
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
1
Directed I/O virtualization (VT-d)
Yes
Intel® Hyper Threading Technology (Intel® HT Technology)
Yes
