MPN:
936-B15921-031
MSI Cubi 3 Silent S-031BEU 1.2L sized PC Black i7-7500U BGA 1356 2.5 GHz
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- Depth
- 110.2 mm
- Wi-Fi
- Y
- Width
- 159.6 mm
- Height
- 69.5 mm
- DVI port
- N
- 64-bit support
- Y
- DC-in jack
- Y
- Idle power states
- Y
- Chassis type
- 1.2L sized PC
1 / 5
Shopping actions
Overview
The MSI Cubi 3 Silent S-031BEU 1.2L sized PC Black i7-7500U BGA 1356 2.5 GHz features Intel Core i7 processor, 2 cores, up to 3.1 GHz boost and Passive cooling. Full verified specifications are listed below.
Technical Specifications
Processor
10 SPECS
Cores
2
Model
i7-7500U
Processor line
Intel Core i7
Socket
BGA 1356
Threads
4
Clock speed
2.5 GHz
Process node
14 nm
CPU brand
Intel
Boost clock
3.1 GHz
TDP
15 W
Memory
2 SPECS
Memory slots
2
Max memory
32 GB
Physical
5 SPECS
Depth
110.2 mm
Width
159.6 mm
Height
69.5 mm
Product type
Mini PC (<= 3L) barebone
Colour
Black
Ports & Connectivity
4 SPECS
HDMI ports
1
DisplayPorts quantity
1
USB 2.0 ports
2
Ethernet ports
2
Cooling
1 SPEC
Cooling type
Passive
General
79 SPECS
Wi-Fi
Yes
DVI port
No
64-bit support
Yes
DC-in jack
Yes
Idle power states
Yes
Chassis type
1.2L sized PC
Ethernet LAN
Yes
HDMI version
2.0
Intel TSX-NI
No
Power supply
65
Microphone input
No
On/off switch
Yes
VESA mounting
Yes
LAN controller
Intel I211
Security lock slot
Yes
Wi-Fi standard
Wi-Fi 5 (802.11ac)
Display included
No
Housing material
Aluminium
Intel® OS Guard
Yes
Headphone outputs
0
Memory slots type
SO-DIMM
Power supply type
External AC adapter
Built-in processor
Yes
COM ports quantity
1
Intel® Insider™
Yes
Intel® Secure Key
Yes
Optical drive type
No
Codename
Kaby Lake
AC adapter included
Yes
DisplayPort version
1.2
Execute Disable (NX)
Yes
Cable lock slot type
Kensington
Graphics card family
Intel
Generation
Intel Core i7-7xxx
Serial ports
2
Card reader
No
Integrated graphics
Yes
Supported memory types
DDR4-SDRAM
CPU configuration (max)
1
Storage drive interface
M.2,PCI Express,Serial ATA III
Combo headphone/mic port
Yes
Intel Flex Memory Access
Yes
PCI Express slots version
3.0
Long-term availability
No
PCI Express configurations
1x2+2x1,1x4,2x2,4x1
VGA ports
0
Compatible processor series
Intel Core i7
Intel Clear Video Technology
Yes
Integrated GPU model
Intel HD Graphics 620
Storage drive sizes supported
2.5
Supported memory clock speeds
2133
Supported storage drive types
HDD & SSD
Intel® InTru™ 3D Technology
Yes
Intel® Turbo Boost Technology
2.0
Number of processors installed
1
Number of processors supported
1
Thermal monitoring
Yes
Intel® Smart Response Technology
Yes
Copper ethernet cabling technology
10BASE-T,100BASE-T,1000BASE-T
Trusted Execution (TXT)
No
Number of storage drives supported
2
SpeedStep power scaling
Yes
Intel® Quick Sync Video Technology
Yes
Windows versions supported
Windows 10,Windows 10 Home,Windows 10 Pro
Virtualization (VT-x)
Yes
Intel® Wireless Display (Intel® WiDi)
Yes
Intel® My WiFi Technology (Intel® MWT)
Yes
Intel Stable Image Platform Program (SIPP)
No
Intel VT-x with Extended Page Tables (EPT)
Yes
Intel® AES New Instructions (Intel® AES-NI)
Yes
Intel® Small Business Advantage (Intel® SBA)
Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
Intel® Clear Video HD Technology (Intel® CVT HD)
Yes
Intel® Identity Protection Technology (Intel® IPT)
Yes
Directed I/O virtualization (VT-d)
Yes
Intel® Hyper Threading Technology (Intel® HT Technology)
Yes
