MSI logo MPN: 9S6-B18311-680

MSI Cubi 10M-215BES 0.66L sized PC Black i3-10110U Intel SoC 2.1 GHz

Released: Not on record
Price not yet available US · Amazon.com

We track this product’s Amazon US price daily — it appears here as soon as it’s listed.

Depth
124 mm
Wi-Fi
Y
Width
124 mm
Height
53.7 mm
Weight
550 g
64-bit support
Y
Bluetooth
Y
Audio chip
Realtek ALC887
DC-in jack
Y
View 93 specifications
1 / 4
Shopping actions
Check price on Amazon

Overview

MSI CLOUD CENTER
FAST, SECURE & WIRELESS BACKUP
Fast, secure, and wireless backup & download between your PC and mobile devices. Transfer files, photos, videos, and more between your PC, Android, and iOS device faster and easier than a cabled connection. You can make these files accessible to your family or team members, or you can also make files as private as you want. The decision is in your hands.

HAND PALM-SIZED PC
MSI Cubi 5 is the smallest mini PC in its kind. With a 0.66 liter case that still provides all the elements of a desktop-worthy PC.

MOUNTABLE TO A MONITOR
Cubi 5 is designed with a mini size and supports standard VESA-mount. Mount the Cubi 5 to the back of a monitor and make the PC completely invisible.

SUPPORT EXTERNAL POWER SWITCH
Making Power Computer much easier. Cubi 5 is designed to support external power switch.
Located computer in a hard to reach area , this is a convenient switch on the desk and hitting it rather than bend down to turn the computer on.

EASY TO UPGRADE
Only remove 4 screws at the bottom cover to gain access and replace the M.2 SSD, memory modules and 2.5” HDD/SSD storage slots. It’s just that simple.

QUIET, ENERGY-EFFICIENT DESIGN
MSI Cubi 5 has an excellent thermal design and low noise fan, resulting in a low noise level of only 23.6 dB of idle mode.

USB 3.2 GEN 1 TYPE-C WITH REVERSIBLE DESIGN
Get all the performance benefits from USB 3.2 Gen1 combined with the convenience of the USB Type-C connector. This reversible connector allows for effortless connecting of USB devices.

DO MORE WORK SIMULTANEOUSLY
Are you watching a lot of webpages and applications on a small monitor? With the HDMI and DP ports,MSI Cubi 5 can support dual monitors, you can do and view more.

Technical Specifications

Processor

9 SPECS
Cache
4 MB
Cores
2
Model
i3-10110U
Processor line
Intel Core i3
Threads
4
Clock speed
2.1 GHz
CPU brand
Intel
Boost clock
4.1 GHz
TDP
15 W

Logistics & Packaging

4 SPECS
Package depth
506 mm
Package width
221 mm
Package height
469 mm
Package weight
1400 g

Graphics

1 SPEC
Max resolution
4096 x 2304

Physical

6 SPECS
Depth
124 mm
Width
124 mm
Height
53.7 mm
Weight
550 g
Product type
Mini PC (<= 3L) barebone
Colour
Black

Ports & Connectivity

4 SPECS
HDMI ports
1
DisplayPorts quantity
1
USB 2.0 ports
2
Ethernet ports
1

Memory

2 SPECS
Memory slots
2
Max memory
64 GB

General

67 SPECS
Wi-Fi
Yes
64-bit support
Yes
Bluetooth
Yes
Audio chip
Realtek ALC887
DC-in jack
Yes
Idle power states
Yes
Chassis type
0.66L sized PC
Ethernet LAN
Yes
HDMI version
1.4
Intel TSX-NI
No
Power supply
65
Certifications
CB/CE, UL (CUL), BSMI, VCCI, RCM (C-Tick)
Microphone input
Yes
On/off switch
Yes
VESA mounting
Yes
LAN controller
Intel I219-V
LED indicators
Yes
Security lock slot
Yes
Wi-Fi standard
Wi-Fi 6 (802.11ax)
Bluetooth version
5.2
Headphone outputs
1
Memory slots type
SO-DIMM
Power supply type
External AC adapter
Quick start guide
Yes
Built-in processor
Yes
Top Wi-Fi standard
Wi-Fi 6 (802.11ax)
AC adapter included
Yes
DisplayPort version
1.2
Execute Disable (NX)
Yes
Chipset
Intel SoC
Power cord included
Yes
Cable lock slot type
Kensington
Graphics card family
Intel
Generation
Intel Core i3-10xxx
Audio channels
2.1
WLAN controller model
Intel Wi-Fi 6 AX201
Integrated graphics
Yes
Supported memory types
DDR4-SDRAM
CPU configuration (max)
1
Compliance certificates
CE,Federal Communications Commission (FCC),RoHS,WEEE
Intel Flex Memory Access
Yes
Panel mounting interface
100 x 100
Storage temperature
-20 - 60
Sustainability compliance
Yes
Long-term availability
No
VGA ports
0
Compatible processor series
Intel Core i3
Operating temperature
0 - 35
Intel Clear Video Technology
Yes
Max graphics memory
32000 GB
Number of displays supported
3
Integrated GPU model
Intel UHD Graphics
Storage drive sizes supported
2.5,M.2
Supported memory clock speeds
2666
Supported storage drive types
HDD & SSD
Number of processors supported
1
Storage relative humidity (H-H)
0 - 90
Operating humidity
0 - 85
Trusted Execution (TXT)
No
Number of storage drives supported
1
SpeedStep power scaling
Yes
Virtualization (VT-x)
Yes
Intel Stable Image Platform Program (SIPP)
No
Intel VT-x with Extended Page Tables (EPT)
Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1
Directed I/O virtualization (VT-d)
Yes
