MPN:
VFY:K5574P132SNL
Fujitsu ESPRIMO K557/24 Intel® Core™ i3 i3-7100T 60.5 cm (23.8″) 1920 x 1080 pixels All-in-One PC 8 GB DDR4-SDRAM 128 GB SSD Windows 10 Pro Black
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- Screen size
- 23.8"
- Resolution
- 1920 x 1080
- Processor line
- Intel Core i3
- Clock speed
- 3.4 GHz
- Capacity
- 8 GB
- Storage
- 128 GB
- Wi-Fi
- Y
- Display type
- Full HD
- Bus type
- DMI3
1 / 7
Shopping actions
Overview
The Fujitsu ESPRIMO K557/24 Intel® Core™ i3 i3-7100T 60.5 cm (23.8″) 1920 x 1080 pixels All-in-One PC 8 GB DDR4-SDRAM 128 GB SSD Windows 10 Pro Black features Intel Core i3 processor, 2 cores, 8 GB of memory and DDR4-SDRAM. Full verified specifications are listed below.
Technical Specifications
Processor
13 SPECS
Stepping
S0
Cache
3 MB
Cores
2
Model
i3-7100T
Processor line
Intel Core i3
Socket
LGA 1151 (Socket H4)
Threads
4
Clock speed
3.4 GHz
Cache level
Smart Cache
Process node
14 nm
CPU brand
Intel
CPU operating modes
64-bit
TDP
35 W
Ports & Connectivity
4 SPECS
HDMI ports
0
DisplayPorts quantity
1
USB 2.0 ports
3
Ethernet ports
1
Physical
2 SPECS
Product type
All-in-One PC
Colour
Black
Display
7 SPECS
Display type
Full HD
Touchscreen
No
LED backlight
Yes
Response time
14 ms
Screen size
23.8"
Resolution
1920 x 1080
Aspect ratio
16:9
Memory
4 SPECS
Capacity
8 GB
Form factor
DIMM/SO-DIMM
Memory type
DDR4-SDRAM
Max memory
32 GB
Logistics & Packaging
3 SPECS
Package depth
400 mm
Package width
705 mm
Package height
607 mm
Storage
2 SPECS
Capacity
128 GB
Storage
128 GB
Graphics
1 SPEC
Memory clock
2400 MHz
General
128 SPECS
Wi-Fi
Yes
Bus type
DMI3
64-bit support
Yes
Bluetooth
Yes
Tjunction
92
Audio chip
Realtek ALC255
DC-in jack
Yes
Idle power states
Yes
Scalability
1S
Audio system
HD
Ethernet LAN
Yes
Intel TSX-NI
No
Memory slots
2
Screen shape
Flat screen
Autonomy mode
No
BIOS password
Yes
Certifications
CE, FCC Class B, cCSAus, WEEE, Microsoft Operating Systems (HCT / HCL entry / WHQL)
Microphone input
Yes
SSD interface
SATA III
Storage media
SSD
Warranty card
Yes
Mouse included
No
Processor code
SR35P
Wall mountable
Yes
Built-in camera
Yes
Security lock slot
Yes
Display surface
Matt
Bus speed
8 GT/s
Wi-Fi standard
Wi-Fi 5 (802.11ac)
AC adapter power
170 W
Intel® OS Guard
Yes
Intel ARK ID
97485
Bluetooth version
4.1
HDD user password
Yes
Headphone outputs
1
Keyboard included
Yes
Memory slots type
DIMM
Depth (with stand)
258
Detachable display
Yes
Display brightness
250
Intel® Secure Key
Yes
Optical drive type
DVD Super Multi
Codename
Kaby Lake
Width (with stand)
560
AC adapter included
Yes
Built-in speaker(s)
Yes
Execute Disable (NX)
Yes
Height (with stand)
446
Weight (with stand)
9700
AC adapter frequency
50/60
Cable lock slot type
Kensington
Intel TSX-NI version
0.00
Number of 5.25" bays
1
Generation
Intel Core i3-7xxx
Configurable TDP-down
25
Depth (no stand)
93 mm
Serial ports
1
Width (no stand)
560 mm
Card reader
No
Dedicated graphics
No
Height (no stand)
368 mm
Integrated graphics
Yes
Processor package size
37.5 x 37.5
Weight (without stand)
6500 g
CPU configuration (max)
1
Compatible memory cards
Not supported
Compliance certificates
RoHS
Conflict-free minerals
Yes
Ethernet LAN data rates
10,100,1000
AC adapter input voltage
100 - 240
Number of SSDs installed
1
Display number of colours
16.78 million colours
Intel Enhanced Halt State
Yes
On-board graphics card ID
0x5912
PCI Express slots version
3.0
ECC memory support
No
Long-term availability
No
Mini DisplayPorts quantity
0
Operating system
Windows 10 Pro
PCI Express configurations
1x16,1x8+2x4,2x8
Instruction sets
AVX 2.0,SSE4.1,SSE4.2
Thunderbolt ports quantity
0
VGA ports
0
Operating temperature
10 - 35
Eco certifications
Blue Angel,ENERGY STAR
Dedicated GPU model
Not available
Intel Clear Video Technology
Yes
Integrated GPU model
Intel HD Graphics 630
Thunderbolt 2 ports quantity
0
Thunderbolt 3 ports quantity
0
Trusted Platform Module (TPM)
Yes
Intel® InTru™ 3D Technology
Yes
Intel® Turbo Boost Technology
No
Thermal solution specification
PCG 2015A
Configurable TDP-down frequency
2.4
Thermal monitoring
Yes
Operating humidity
5 - 85
Trusted Execution (TXT)
No
SpeedStep power scaling
Yes
Intel Secure Key Technology version
1.00
Intel® Quick Sync Video Technology
Yes
PCIe lanes
16
Memory types supported by processor
DDR3L-SDRAM,DDR4-SDRAM
Maximum on-board graphics card memory
64
On-board graphics card OpenGL version
4.4
On-board graphics card base frequency
350
Virtualization (VT-x)
Yes
Memory channels supported by processor
Dual
On-board graphics card DirectX version
12.0
Intel Stable Image Platform Program (SIPP)
No
Intel VT-x with Extended Page Tables (EPT)
Yes
Memory clock speeds supported by processor
1333,1600,2133,2400
Intel Software Guard Extensions (Intel SGX)
Yes
Intel Identity Protection Technology version
1.00
Intel® AES New Instructions (Intel® AES-NI)
Yes
Maximum internal memory supported by processor
64
On-board graphics card dynamic frequency (max)
1100
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
Number of displays supported (on-board graphics)
3
Intel Stable Image Platform Program (SIPP) version
0.00
Intel® Clear Video HD Technology (Intel® CVT HD)
Yes
Intel® Identity Protection Technology (Intel® IPT)
Yes
Directed I/O virtualization (VT-d)
Yes
Intel® Hyper Threading Technology (Intel® HT Technology)
Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
Yes
