MPN:
9PA6003004
FSP FSP600-80BPN power supply unit 600 W 24-pin ATX ATX Black
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- Wattage
- 600 W
- Depth
- 140 mm
- Width
- 150 mm
- Height
- 86 mm
- Weight
- 1850 g
- Purpose
- PC
- Fan speed
- 1650
- Hold time
- 16
- Rise time
- 20
1 / 2
Shopping actions
Overview
The FSP FSP600-80BPN power supply unit 600 W 24-pin ATX ATX Black features 600 W output, a 120 mm fan and Active cooling. Full verified specifications are listed below.
Technical Specifications
Physical
5 SPECS
Depth
140 mm
Width
150 mm
Height
86 mm
Weight
1850 g
Colour
Black
Power
1 SPEC
Wattage
600 W
Cooling
3 SPECS
Cooling type
Active
Fan size
120
Number of fans
1
Logistics & Packaging
2 SPECS
Country of origin
China
Products per pallet
480
General
44 SPECS
Purpose
PC
Fan speed
1650
Hold time
16
Rise time
20
Efficiency
85
Peak power
650
ATX version
2.31
EPS version
2.92
Noise level
30
Cabling type
Non-Modular
Fan location
Top
Power factor
0.98
Monitor outlet
No
Voltage tolerance
10
AC input frequency
50
Frequency tolerance
5
Combined power (+5V)
120
Combined power (+12V)
504
Combined power (-12V)
6
Combined power (+3.3V)
85.8
Combined power (+5Vsb)
17.5
Compliance certificates
RoHS
Max output current (+5V)
24
Max output current (+12V)
18
Max output current (-12V)
0.5
Power protection features
Over current,Over voltage,Short circuit,Under voltage,Overload
Storage temperature
-40 - 70
Max output current (+3.3V)
26
Max output current (+5Vsb)
3.5
EPS power connector (8-pin)
No
Motherboard power connector
24-pin ATX
Operating temperature
0 - 40
ATX Power connector (24-pin)
Yes
Floppy drive power connector
1
CPU power connector (4+4 pin)
Yes
Number of SATA power connectors
6
Storage relative humidity (H-H)
5 - 95
MTBF
100000 h
Operating humidity
5 - 85
Power Factor Correction (PFC) type
Active
Power supply unit (PSU) form factor
ATX
Redundant power supply (RPS) support
No
PCI Express power connectors (6+2 pin)
2
Peripheral (Molex) power connectors (4-pin)
2
