MPN:
SFX-500GD-C
Chieftec SFX-500GD-C power supply unit 500 W 20+4 pin ATX Black
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- Wattage
- 500 W
- Efficiency rating
- 80 PLUS Gold
- Depth
- 125 mm
- Width
- 125 mm
- Height
- 64 mm
- ATX version
- 2.3
- Cabling type
- Fully-Modular
- Fan size
- 120
- Input current
- 7
1 / 6
Shopping actions
Overview
The Chieftec SFX-500GD-C power supply unit 500 W 20+4 pin ATX Black features 500 W output, 80 PLUS 80 PLUS Gold efficiency and a 120 mm fan. Full verified specifications are listed below.
Technical Specifications
Physical
4 SPECS
Depth
125 mm
Width
125 mm
Height
64 mm
Colour
Black
Power
2 SPECS
Wattage
500 W
Efficiency rating
80 PLUS Gold
Cooling
2 SPECS
Fan size
120
Number of fans
1
General
28 SPECS
ATX version
2.3
Cabling type
Fully-Modular
Input current
7
AC input voltage
100 - 240
AC input frequency
50 - 60
Frequency tolerance
90
Combined power (+5V)
105
Combined power (-12V)
3.6
Combined power (+3.3V)
105
Combined power (+5Vsb)
15
Compliance certificates
RoHS
CPU P4 connector (4-pin)
1
Max output current (+5V)
20
Max output current (-12V)
0.3
Power protection features
Over current,Over voltage,Overload,Short circuit,Under voltage
Max output current (+12V1)
40
Max output current (+3.3V)
20
Max output current (+5Vsb)
3
EPS power connector (8-pin)
Yes
Motherboard power connector
20+4 pin ATX
Floppy drive power connector
0
Number of SATA power connectors
4
Power Factor Correction (PFC) type
Active
Power supply unit (PSU) form factor
SFX
PCI Express power connectors (6-pin)
0
PCI Express power connectors (8-pin)
1
PCI Express power connectors (6+2 pin)
2
Peripheral (Molex) power connectors (4-pin)
2
Market Value History
Price history not started yet
Daily price tracking begins as soon as this product is listed on Amazon US — the trend chart will appear here automatically.
Sources
Product lifecycle
In production
Still listed as on-market by the manufacturer — actively sold and supported.
Lifecycle status is derived from catalog data and is indicative, not a manufacturer support guarantee.
