MPN:
GPU-650FC
Chieftec PowerPlay power supply unit 650 W 20+4 pin ATX PS/2 Black, Red
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- Wattage
- 650 W
- Efficiency rating
- 80 PLUS Gold
- Depth
- 160 mm
- Width
- 150 mm
- Height
- 86 mm
- Weight
- 2360 g
- Purpose
- PC
- ATX version
- 2.3
- Cabling type
- Fully-Modular
1 / 9
Shopping actions
Overview
The Chieftec PowerPlay power supply unit 650 W 20+4 pin ATX PS/2 Black, Red features 650 W output, 80 PLUS 80 PLUS Gold efficiency, a 140 mm fan and Active cooling. Full verified specifications are listed below.
Technical Specifications
Physical
6 SPECS
Depth
160 mm
Width
150 mm
Height
86 mm
Weight
2360 g
Colour
Black,Red
Customs (HS) code
84733020
Logistics & Packaging
1 SPEC
Package weight
2770 g
Cooling
3 SPECS
Cooling type
Active
Fan size
140
Number of fans
1
Power
2 SPECS
Wattage
650 W
Efficiency rating
80 PLUS Gold
General
36 SPECS
Purpose
PC
ATX version
2.3
Cabling type
Fully-Modular
Fan location
Top
Packaging type
Box
Power factor
0.9
Input current
10
On/off switch
Yes
AC input voltage
100 - 240
AC input frequency
47 - 63
Combined power (+5V)
120
Combined power (+12V)
650.4
Combined power (-12V)
3.6
PCI Express connector
Yes
Combined power (+3.3V)
120
Combined power (+5Vsb)
15
SATA power cable length
150,800
Max output current (+5V)
22
Max output current (+12V)
54.2
Max output current (-12V)
0.3
Power protection features
Over current,Over power,Over voltage,Overheating,Short circuit
Max output current (+3.3V)
22
Max output current (+5Vsb)
3
EPS power connector (8-pin)
Yes
Floppy disk drive connector
Yes
Motherboard power connector
20+4 pin ATX
Floppy drive power connector
1
ATX power connector (20+4 pin)
Yes
Motherboard power cable length
600
PCI Express power cable length
600
Number of SATA power connectors
9
Power Factor Correction (PFC) type
Active
Power supply unit (PSU) form factor
PS/2
Peripheral (Molex) power cable length
150,700
PCI Express power connectors (6+2 pin)
4
Peripheral (Molex) power connectors (4-pin)
3
Market Value History
Sources
Product lifecycle
In production
Still listed as on-market by the manufacturer — actively sold and supported.
Lifecycle status is derived from catalog data and is indicative, not a manufacturer support guarantee.
