MPN:
BN197
be quiet! Straight Power E9 CM power supply unit 480 W 20+4 pin ATX ATX Black
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- Wattage
- 480 W
- Efficiency rating
- 80 PLUS Gold
- Depth
- 150 mm
- Width
- 160 mm
- Height
- 86 mm
- Weight
- 2410 g
- Purpose
- PC
- Fan speed
- 920
- Hold time
- 19
1 / 5
Shopping actions
Overview
The be quiet! Straight Power E9 CM power supply unit 480 W 20+4 pin ATX ATX Black features 480 W output, 80 PLUS 80 PLUS Gold efficiency, a 135 mm fan and Active cooling. Full verified specifications are listed below.
Technical Specifications
Physical
5 SPECS
Depth
150 mm
Width
160 mm
Height
86 mm
Weight
2410 g
Colour
Black
Logistics & Packaging
1 SPEC
Package weight
2820 g
Cooling
3 SPECS
Cooling type
Active
Fan size
135
Number of fans
1
Power
2 SPECS
Wattage
480 W
Efficiency rating
80 PLUS Gold
General
44 SPECS
Purpose
PC
Fan speed
920
Hold time
19
Efficiency
92.8
Peak power
550
ATX version
2.31
Noise level
18.8
Cabling type
Semi-Modular
Power factor
0.99
Certifications
CE, CB, TÜV, Semko (S)
Input current
4 - 8
AC input voltage
100 - 240
AC input frequency
50 - 60
Bearing type
FDB
Combined power (+5V)
130
Combined power (+12V)
456
Combined power (+3.3V)
130
Compliance certificates
RoHS
CPU P4 connector (4-pin)
1
Max output current (+5V)
22
Max output current (+12V)
38
Max output current (-12V)
0.3
Power protection features
Over current,Over power,Over voltage,Overheating,Short circuit,Under voltage
Max output current (+12V1)
18
Max output current (+12V2)
18
Max output current (+12V3)
18
Max output current (+12V4)
18
Max output current (+3.3V)
24
Max output current (+5Vsb)
3
Package dimensions (WxDxH)
328 x 248 x 102
Motherboard power connector
20+4 pin ATX
Operating temperature
0 - 40
Eco certifications
ENERGY STAR
Floppy drive power connector
1
CPU power connector (4+4 pin)
Yes
Maximum input current (@110V)
+12V1,+12V2,+12V3,+12V4,+3.3V,+5V,+5Vsb,-12V
Noise level (silent mode, <30%)
13.7
Number of SATA power connectors
8
MTBF
300000 h
Noise level (full-load mode, 100%)
18.8
Power Factor Correction (PFC) type
Active
Power supply unit (PSU) form factor
ATX
PCI Express power connectors (6+2 pin)
2
Peripheral (Molex) power connectors (4-pin)
4
