MPN:
BN230
be quiet! Straight Power 10 power supply unit 400 W 20+4 pin ATX ATX Black
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- Wattage
- 400 W
- Efficiency rating
- 80 PLUS Gold
- Depth
- 150 mm
- Width
- 160 mm
- Height
- 86 mm
- Manual included
- Y
- Safety
- CE, CB, TÜV, FCC, cRUus, cTUVus, BSMI
- Weight
- 2020 g
- Purpose
- PC
1 / 6
Shopping actions
Overview
The be quiet! Straight Power 10 power supply unit 400 W 20+4 pin ATX ATX Black features 400 W output, 80 PLUS 80 PLUS Gold efficiency, a 135 mm fan and Active cooling. Full verified specifications are listed below.
Technical Specifications
Physical
5 SPECS
Depth
150 mm
Width
160 mm
Height
86 mm
Weight
2020 g
Colour
Black
Power
2 SPECS
Wattage
400 W
Efficiency rating
80 PLUS Gold
Logistics & Packaging
4 SPECS
Package depth
248 mm
Package width
328 mm
Package height
102 mm
Package weight
2590 g
Cooling
3 SPECS
Cooling type
Active
Fan size
135
Number of fans
1
General
45 SPECS
Manual included
Yes
Safety
CE, CB, TÜV, FCC, cRUus, cTUVus, BSMI
Purpose
PC
Fan speed
1200
Hold time
17
Efficiency
93
Peak power
450
ATX version
2.4
Cabling type
Non-Modular
Packaging type
Box
Power factor
0.97
Input current
6
Warranty card
Yes
AC input voltage
100 - 240
AC input frequency
50 - 60
Bearing type
FDB
Combined power (+5V)
120
Combined power (+12V)
384
Combined power (-12V)
3.6
Combined power (+3.3V)
120
Combined power (+5Vsb)
15
Compliance certificates
RoHS
Max output current (+5V)
17
Max output current (-12V)
0.3
Power protection features
Over current,Over power,Over voltage,Overheating,Short circuit,Under voltage
Max output current (+12V1)
18
Max output current (+12V2)
18
Max output current (+12V3)
18
Max output current (+3.3V)
24
Max output current (+5Vsb)
3
Floppy disk drive connector
Yes
Motherboard power connector
20+4 pin ATX
Eco certifications
ENERGY STAR
Floppy drive power connector
1
CPU power connector (4+4 pin)
Yes
Maximum input current (@110V)
+12V1,+12V2,+12V3,+3.3V,+5V,+5Vsb,-12V
Noise level (quiet mode, 50%)
10.4
Noise level (silent mode, <30%)
10.4
Number of SATA power connectors
6
MTBF
100000 h
Noise level (full-load mode, 100%)
11.7
Power Factor Correction (PFC) type
Active
Power supply unit (PSU) form factor
ATX
PCI Express power connectors (6+2 pin)
2
Peripheral (Molex) power connectors (4-pin)
3
