MPN:
X470 GAMING PLUS MAX
MSI X470 Gaming Plus Max AMD X470 Socket AM4 ATX
Released: Not on record
$249.99
from
US · Amazon.com
Updated 2 weeks ago
Last updated Sep 3, 2026 03:13 UTC
Ratings & price sourced from Amazon.com (United States).
- Depth
- 244 mm
- Wi-Fi
- N
- Width
- 305 mm
- Audio chip
- Realtek ALC892 / Realtek ALC897
- RAID levels
- 0,1,10
- Ethernet LAN
- Y
- Intended use
- PC
- TPM connector
- Y
- LAN controller
- Realtek 8111H
1 / 5
Shopping actions
Overview
The MSI X470 Gaming Plus Max AMD X470 Socket AM4 ATX (Depth: 244 mm). Full verified specifications are listed below.
Technical Specifications
Ports & Connectivity
5 SPECS
HDMI ports
1
PS/2 ports
1
DVI-D ports quantity
1
USB 2.0 ports
2
Ethernet ports
1
Graphics
2 SPECS
DirectX version
12.0
Max resolution
4096 x 2160
Physical
4 SPECS
Depth
244 mm
Width
305 mm
Form factor
ATX
Customs (HS) code
84733020
Processor
2 SPECS
Socket
Socket AM4
CPU brand
AMD
Memory
2 SPECS
Memory slots
4
Max memory
128 GB
General
43 SPECS
Wi-Fi
No
Audio chip
Realtek ALC892 / Realtek ALC897
RAID levels
0,1,10
Ethernet LAN
Yes
Intended use
PC
TPM connector
Yes
LAN controller
Realtek 8111H
Memory channels
Dual-channel
CPU fan connector
Yes
Memory slots type
DIMM
ECC сompatibility
non-ECC
Parallel connector
Yes
RGB LED pin header
Yes
USB 2.0 connectors
4
Chipset
AMD X470
Serial port headers
1
PCI Express x1 slots
3
eSATA ports quantity
0
Audio channels
7.1
PCI Express x16 slots
2
Supported memory types
DDR4-SDRAM
Ethernet interface type
Gigabit Ethernet
Number of M.2 (M) slots
2
FireWire ports
0
Motherboard chipset family
AMD
VGA ports
0
Compatible processor series
AMD Athlon,AMD Ryzen 2000 Series,AMD Ryzen 3000 Series
EPS power connector (8-pin)
Yes
ATX Power connector (24-pin)
Yes
Number of SATA II connectors
0
Number of SATA III connectors
6
Supported memory clock speeds
1866,2133,2400,2667,2800,2933,3000,3066,3200,3466,3600,3733,3866,4000,4133
Number of Parallel ATA connectors
0
Supported storage drive interfaces
SATA III
Windows versions supported
Windows 10 x64
USB 3.2 Gen 1 (3.1 Gen 1) connectors
4
USB 3.2 Gen 2 (3.1 Gen 2) connectors
0
Parallel processing technology support
Crossfire
Peripheral (Molex) power connectors (4-pin)
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
Market Value History
Sources
Product lifecycle
In production
Still listed as on-market by the manufacturer — actively sold and supported.
Lifecycle status is derived from catalog data and is indicative, not a manufacturer support guarantee.
