MPN:
911-7B84-001
MSI A320M PRO-M2 AMD A320 Socket AM4 micro ATX
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- Depth
- 206 mm
- Wi-Fi
- N
- Width
- 244 mm
- BIOS type
- UEFI AMI
- Audio chip
- Realtek ALC887
- RAID levels
- 0,1,10
- ACPI version
- 5.0
- Ethernet LAN
- Y
- HDMI version
- 1.4
1 / 5
Shopping actions
Overview
The MSI A320M PRO-M2 AMD A320 Socket AM4 micro ATX (Depth: 206 mm). Full verified specifications are listed below.
Technical Specifications
Ports & Connectivity
5 SPECS
HDMI ports
1
PS/2 ports
1
DVI-D ports quantity
1
USB 2.0 ports
2
Ethernet ports
1
Memory
2 SPECS
Memory slots
2
Max memory
32 GB
Physical
3 SPECS
Depth
206 mm
Width
244 mm
Form factor
Micro ATX
Processor
2 SPECS
Socket
Socket AM4
CPU brand
AMD
Graphics
1 SPEC
Max resolution
4096 x 2160
General
58 SPECS
Wi-Fi
No
BIOS type
UEFI AMI
Audio chip
Realtek ALC887
RAID levels
0,1,10
ACPI version
5.0
Ethernet LAN
Yes
HDMI version
1.4
Intended use
PC
TPM connector
Yes
LAN controller
Realtek 8111H
Included cables
SATA
Memory channels
Dual-channel
BIOS memory size
128 MB
Drivers included
Yes
CPU fan connector
Yes
Clear CMOS jumper
Yes
Memory slots type
DIMM
Unbuffered memory
Yes
ECC сompatibility
ECC & non-ECC
USB 2.0 connectors
2
12V power connector
Yes
Chipset
AMD A320
Serial port headers
1
PC health monitoring
CPU,FAN,Temperature
eSATA ports quantity
0
Audio channels
7.1
Front panel connector
Yes
Supported memory types
DDR4-SDRAM
Ethernet interface type
Gigabit Ethernet
Number of M.2 (M) slots
1
Number of mounting holes
4
Quick installation guide
Yes
FireWire ports
0
Motherboard chipset family
AMD
VGA ports
1
Chassis intrusion connector
Yes
Compatible processor series
AMD A,AMD Athlon,AMD Ryzen 2000 Series,AMD Ryzen 3000 Series
Front panel audio connector
Yes
Supported CPU sockets
Socket AM4
ATX Power connector (24-pin)
Yes
Number of SATA II connectors
0
Number of SATA III connectors
4
Supported memory clock speeds
1866,2133,2400,2667,2933,3200
Supported storage drive types
HDD & SSD
PCI Express x1 (Gen 2.x) slots
2
PCI Express x16 (Gen 3.x) slots
1
Maximum number of SMP processors
1
Number of chassis fan connectors
1
Number of Parallel ATA connectors
0
Supported storage drive interfaces
SATA III
Windows versions supported
Windows 10,Windows 7
USB 3.2 Gen 1 (3.1 Gen 1) connectors
1
USB 3.2 Gen 2 (3.1 Gen 2) connectors
0
System Management BIOS (SMBIOS) version
2.8
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
