MPN:
Z890 AORUS PRO ICE
GIGABYTE Z890 AORUS PRO ICE Motherboard – Supports Intel Core Ultra (Series 2) CPUs, 16+1+2 phases VRM, up to 9500MHz DDR5 (OC), 1xPCIe 5.0 + 4xPCIe 4.0, Wi-Fi 7, 5GbE LAN, Thunderbolt 4
Released: Oct 24, 2024
2 years ago
$229.95
$399.99
▼ 43% ($170.04 off)
vs MSRP
from
US · Amazon.com
Updated 2 months ago
Last updated Sep 3, 2026 03:13 UTC
Ratings & price sourced from Amazon.com (United States).
- Depth
- 244 mm
- Wi-Fi
- Y
- Width
- 305 mm
- Height
- 35 mm
- Weight
- 2270 g
- BIOS type
- UEFI AMI
- Bluetooth
- Y
- Audio chip
- Realtek ALC1220
- RAID levels
- 0,1,5,10
Shopping actions
Overview
Elevate your computing experience with GIGABYTE's renowned motherboard series: AORUS, AERO, and GIGABYTE. Featuring innovative designs and advanced features, these boards offer exceptional performance and reliability. Whether you're a gamer, content creator, or professional, our series cater to your needs, ensuring uncompromising quality and cutting-edge
Technical Specifications
Physical
6 SPECS
Depth
244 mm
Width
305 mm
Height
35 mm
Weight
2270 g
Colour
White
Form factor
ATX
Processor
3 SPECS
Bundled software
Norton® Internet Security (OEM version)
LAN bandwidth management software
Socket
LGA 1851 (Socket V1)
CPU brand
Intel
Memory
2 SPECS
Memory slots
4
Max memory
256 GB
Storage
1 SPEC
SATA ports
0
Ports & Connectivity
5 SPECS
HDMI ports
1
DVI-D ports quantity
0
DisplayPorts quantity
2
USB 2.0 ports
4
Ethernet ports
1
Logistics & Packaging
5 SPECS
Package depth
270 mm
Package width
335 mm
Package height
80 mm
Package weight
2550 g
Country of origin
China
Graphics
1 SPEC
DirectX version
12.0
General
72 SPECS
Wi-Fi
Yes
BIOS type
UEFI AMI
Bluetooth
Yes
Audio chip
Realtek ALC1220
RAID levels
0,1,5,10
ACPI version
5.0
Battery type
CR2032
Ethernet LAN
Yes
RAID support
Yes
Intended use
PC
Microphone input
Yes
TPM connector
Yes
Battery weight
3
Memory channels
Dual-channel
S/PDIF out port
Yes
Warranty period
3
Wi-Fi standard
Wi-Fi 7 (802.11be)
BIOS memory size
256 MB
Bluetooth version
5.4
Clear CMOS button
Yes
Clear CMOS jumper
Yes
Memory slots type
DIMM
Batteries included
Yes
Battery technology
Lithium-Manganese Dioxide (LiMnO2)
ECC сompatibility
non-ECC
RGB LED pin header
Yes
Top Wi-Fi standard
Wi-Fi 7 (802.11be)
USB 2.0 connectors
2
12V power connector
Yes
Chipset
Intel Z890
PC health monitoring
FAN,Temperature,Voltage
mSATA ports quantity
0
Audio channels
7.1
WLAN controller model
Intel Wi-Fi 7 BE200
Integrated graphics
No
Supported memory types
DDR5-SDRAM
Ethernet interface type
5 Gigabit Ethernet
Number of M.2 (M) slots
5
Number of battery cells
1
Number of HDDs supported
9
Lithium weight per battery
0.07
Motherboard chipset family
Intel
Thunderbolt ports quantity
2
USB 3.2 Gen 2x2 connectors
1
VGA ports
0
Compatible processor series
Intel Core Ultra (Series 2)
EPS power connector (8-pin)
Yes
Supported CPU sockets
LGA 1851
ATX Power connector (24-pin)
Yes
Number of SATA II connectors
0
Number of SATA III connectors
4
Supported memory clock speeds
5600,5800,6000,6200,6400,6600,6800,7000,7200,7400,7600,7800,7900,7950,8000,8200,8266,8400,8600,9500
Supported storage drive types
HDD & SSD
PCI Express x16 (Gen 4.x) slots
2
PCI Express x16 (Gen 5.x) slots
1
Total number of SATA connectors
4
Number of storage drives supported
4
Products per shipping (inner) case
1
Supported memory clock speed (max)
9500
Supported memory module capacities
1GB,2GB,4GB,8GB,12GB,16GB,24GB,32GB,40GB,48GB,64GB
Supported storage drive interfaces
M.2,SATA III
Windows versions supported
Windows 11 x64
USB 3.2 Gen 1 (3.1 Gen 1) connectors
1
USB 3.2 Gen 2 (3.1 Gen 2) connectors
0
Number of EPS power connectors (8-pin)
2
System Management BIOS (SMBIOS) version
2.7
Desktop Management Interface (DMI) version
2.7
Maximum internal memory supported by processor
256
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
Market Value History
Sources
Product lifecycle
In production
Launched
2024
Still listed as on-market by the manufacturer — actively sold and supported.
Lifecycle status is derived from catalog data and is indicative, not a manufacturer support guarantee.
