MPN:
GA-J1900N-D3V
GIGABYTE GA-J1900N-D3V (rev. 1.0) mini ITX
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- Depth
- 170 mm
- Width
- 170 mm
- BIOS type
- UEFI AMI
- PCI slots
- Y
- Audio chip
- Realtek ALC887
- ACPI version
- 2.0a
- Ethernet LAN
- Y
- Intended use
- PC
- Graphics card
- HD Graphics
1 / 4
Shopping actions
Overview
The GIGABYTE GA-J1900N-D3V (rev. 1.0) mini ITX (Depth: 170 mm). Full verified specifications are listed below.
Technical Specifications
Ports & Connectivity
5 SPECS
HDMI ports
0
PS/2 ports
2
DVI-D ports quantity
1
USB 2.0 ports
0
Ethernet ports
2
Memory
2 SPECS
Memory slots
2
Max memory
8 GB
Storage
1 SPEC
SATA ports
2
Processor
3 SPECS
Model
J1900
Bundled software
Norton Internet Security, Intel Smart Connect Technology
CPU brand
Intel
Physical
3 SPECS
Depth
170 mm
Width
170 mm
Form factor
Mini ITX
Graphics
1 SPEC
Max resolution
2560 x 1600
Power
1 SPEC
Power source
ATX
General
42 SPECS
BIOS type
UEFI AMI
PCI slots
1
Audio chip
Realtek ALC887
ACPI version
2.0a
Ethernet LAN
Yes
Intended use
PC
Graphics card
HD Graphics
Microphone input
Yes
Memory channels
Dual-channel
BIOS memory size
128 MB
CPU fan connector
Yes
Clear CMOS jumper
Yes
Headphone outputs
1
Memory slots type
SO-DIMM
ECC сompatibility
non-ECC
Parallel connector
Yes
USB 2.0 connectors
1
Graphics card family
Intel
PC health monitoring
CPU,FAN,Power supply,Temperature
S/PDIF out connector
Yes
eSATA ports quantity
0
Audio channels
7.1
Serial ports
2
Mini PCI Express slots
1
Supported memory types
DDR3-SDRAM
Ethernet interface type
Gigabit Ethernet
FireWire ports
0
VGA ports
1
Chassis intrusion connector
Yes
Compatible processor series
Intel Celeron
Front panel audio connector
Yes
ATX Power connector (24-pin)
Yes
Number of SATA II connectors
2
Number of SATA III connectors
0
Supported memory clock speeds
1333
Number of chassis fan connectors
2
Number of Parallel ATA connectors
0
Supported storage drive interfaces
SATA II
Windows versions supported
Windows 8 Enterprise x64,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64
Parallel processing technology support
Not supported
Peripheral (Molex) power connectors (4-pin)
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
