MPN:
9FX09AV
HP Intel Xeon W-1250P processor 4.1 GHz 12 MB Smart Cache
Released: Not on record
Price not yet available
US · Amazon.com
We track this product’s Amazon US price daily — it appears here as soon as it’s listed.
- Cores
- 6
- Threads
- 12
- Base clock
- 4.1 GHz
- Boost clock
- 4.8 GHz
- Socket
- LGA 1200 (Socket H5)
- TDP
- 125 W
- Processor line
- Intel Xeon W
- Cache
- 12 MB
- Process node
- 14 nm
Shopping actions
Overview
The HP Intel Xeon W-1250P processor 4.1 GHz 12 MB Smart Cache features Intel Xeon W processor, 6 cores, a 4.1 GHz base clock and up to 4.8 GHz boost. Full verified specifications are listed below.
Technical Specifications
Processor
13 SPECS
Cache
12 MB
Cores
6
Model
W-1250P
Processor line
Intel Xeon W
Socket
LGA 1200 (Socket H5)
Threads
12
Cache level
Smart Cache
Process node
14 nm
CPU brand
Intel
Base clock
4.1 GHz
Boost clock
4.8 GHz
CPU operating modes
64-bit
TDP
125 W
Memory
2 SPECS
ECC support
Yes
Max memory
128 GB
Physical
2 SPECS
Product type
Processor
Customs (HS) code
85423119
General
77 SPECS
Status
Launched
64-bit support
Yes
Bus speed
8 GT/s
Tjunction
100
Idle power states
Yes
Launch date
Q2'20
Scalability
1S
Processor ID
0x9BC6
Intended use
Server/Workstation
Market segment
Workstation
Maximum memory
128
Memory channels
Dual-channel
Bus speed
8 GT/s
Intel® OS Guard
Yes
Intel ARK ID
199340
Intel® Boot Guard
Yes
Intel® Secure Key
Yes
Codename
Comet Lake
Execute Disable (NX)
Yes
Configurable TDP-down
95
Dedicated graphics
No
Integrated graphics
Yes
Supported memory types
DDR4-SDRAM
CPU configuration (max)
1
PCI Express CEM revision
3.0
On-board graphics card ID
0x9BC6
PCI Express slots version
3.0
Long-term availability
No
PCI Express configurations
1x16,2x8,1x8+2x4
Instruction sets
SSE4.1,SSE4.2,AVX 2.0
Dedicated GPU model
Not available
Intel Clear Video Technology
Yes
Max graphics memory
64 GB
Integrated GPU model
Intel UHD Graphics P630
Intel® InTru™ 3D Technology
Yes
Intel® Optane™ Memory Ready
Yes
Intel® Thermal Velocity Boost
No
Intel® Turbo Boost Technology
2.0
Thermal solution specification
PCG 2015D
Configurable TDP-down frequency
3.8
Thermal monitoring
Yes
On-board graphics card 4K support
Yes
Trusted Execution (TXT)
Yes
SpeedStep power scaling
Yes
Intel® Quick Sync Video Technology
Yes
PCIe lanes
16
Memory types supported by processor
DDR4-SDRAM
Intel Turbo Boost Max Technology 3.0
No
Intel® vPro™ Platform Eligibility
Yes
Maximum on-board graphics card memory
64
On-board graphics card OpenGL version
4.5
On-board graphics card base frequency
350
Virtualization (VT-x)
Yes
On-board graphics card DirectX version
12.0
Intel VT-x with Extended Page Tables (EPT)
Yes
Memory clock speeds supported by processor
2666
Export Control Classification Number (ECCN)
5A992C
Intel Software Guard Extensions (Intel SGX)
Yes
Intel® Turbo Boost Technology 2.0 frequency
4.8
Intel® AES New Instructions (Intel® AES-NI)
Yes
Memory bandwidth supported by processor (max)
41.6
Maximum internal memory supported by processor
128
On-board graphics card dynamic frequency (max)
1200
Maximum resolution & refresh rate (DisplayPort)
4096x2304@60Hz
Intel® Transactional Synchronization Extensions
No
Number of displays supported (on-board graphics)
3
On-board graphics card maximum resolution (HDMI)
4096 x 2160
Intel® Clear Video HD Technology (Intel® CVT HD)
Yes
Intel® Identity Protection Technology (Intel® IPT)
Yes
Directed I/O virtualization (VT-d)
Yes
On-board graphics card maximum resolution (DisplayPort)
4096 x 2304
Commodity Classification Automated Tracking System (CCATS)
G077159
Intel® Hyper Threading Technology (Intel® HT Technology)
Yes
On-board graphics card refresh rate at maximum resolution (HDMI)
30
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)
4096 x 2304
On-board graphics card refresh rate at maximum resolution (DisplayPort)
60
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)
60
