DELL logo MPN: 338-BUJC

DELL Xeon E-2246G processor 3.6 GHz 12 MB Smart Cache Tray

Released: Not on record
Price not yet available US · Amazon.com

We track this product’s Amazon US price daily — it appears here as soon as it’s listed.

Cores
6
Threads
12
Base clock
3.6 GHz
Boost clock
4.8 GHz
Socket
LGA 1151 (Socket H4)
TDP
80 W
Processor line
Intel Xeon E
Cache
12 MB
Process node
14 nm
View 93 specifications
1 / 4
Shopping actions
Check price on Amazon

Overview

The Intel Xeon® E-2246G 3.6GHz Six Core Processor enhances the performance and the speed of your system. Additionally, the Virtualization Technology enables migration of more environments. It supports enhanced SpeedStep® technology that allows tradeoffs to be made between performance and power consumption.

Its Thermal Monitoring Technologies protect the processor package and the system from thermal failure through several thermal management features. The VT-x with Extended Page Tables (EPT) also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Packed with more features, the Xeon E-2246G 3.6GHz Six Core Processor is the ideal choice for virtually all of your data demanding or standard enterprise infrastructure applications.

Technical Specifications

Processor

13 SPECS
Cache
12 MB
Cores
6
Model
E-2246G
Processor line
Intel Xeon E
Socket
LGA 1151 (Socket H4)
Threads
12
Cache level
Smart Cache
Process node
14 nm
CPU brand
Intel
Base clock
3.6 GHz
Boost clock
4.8 GHz
CPU operating modes
64-bit
TDP
80 W

Memory

2 SPECS
ECC support
Yes
Max memory
128 GB

Physical

2 SPECS
Product type
Processor
Customs (HS) code
8542310001

General

76 SPECS
Max case temperature (Tcase)
73 °C
Status
Launched
64-bit support
Yes
Bus speed
8 GT/s
Tjunction
100
Idle power states
Yes
Launch date
Q2'19
Scalability
1S
Intel TSX-NI
Yes
Packaging type
Tray
Processor ID
0x3E96
Intended use
Server/Workstation
Market segment
Server
Maximum memory
128
Cooler included
No
Memory channels
Dual-channel
Bus speed
8 GT/s
Intel® OS Guard
Yes
Intel ARK ID
191043
Intel® Boot Guard
Yes
Intel® Secure Key
Yes
Codename
Coffee Lake
Execute Disable (NX)
Yes
Dedicated graphics
No
Integrated graphics
Yes
Processor package size
37.5mm x 37.5mm
Supported memory types
DDR4-SDRAM
CPU configuration (max)
1
PCI Express CEM revision
3.0
On-board graphics card ID
0x3E96
PCI Express slots version
3.0
Long-term availability
No
PCI Express configurations
1x16,2x8,1x8+2x4
Instruction sets
SSE4.1,SSE4.2,AVX 2.0
Dedicated GPU model
Not available
Intel Clear Video Technology
Yes
Max graphics memory
128 GB
Integrated GPU model
Intel UHD Graphics P630
Intel® InTru™ 3D Technology
Yes
Intel® Optane™ Memory Ready
Yes
Intel® Turbo Boost Technology
2.0
Thermal monitoring
Yes
On-board graphics card 4K support
Yes
Trusted Execution (TXT)
Yes
SpeedStep power scaling
Yes
Intel® Quick Sync Video Technology
Yes
PCIe lanes
16
Memory types supported by processor
DDR4-SDRAM
Intel® vPro™ Platform Eligibility
Yes
Maximum on-board graphics card memory
128
On-board graphics card OpenGL version
4.5
On-board graphics card base frequency
350
Virtualization (VT-x)
Yes
On-board graphics card DirectX version
12.0
Intel VT-x with Extended Page Tables (EPT)
Yes
Memory clock speeds supported by processor
2666
Export Control Classification Number (ECCN)
5A992C
Intel Software Guard Extensions (Intel SGX)
Yes
Intel® Turbo Boost Technology 2.0 frequency
4.8
Intel® AES New Instructions (Intel® AES-NI)
Yes
Maximum internal memory supported by processor
128
On-board graphics card dynamic frequency (max)
1200
Maximum resolution & refresh rate (DisplayPort)
4096x2304@60Hz
Intel® Transactional Synchronization Extensions
Yes
Number of displays supported (on-board graphics)
3
On-board graphics card maximum resolution (HDMI)
4096 x 2160
Intel® Clear Video HD Technology (Intel® CVT HD)
Yes
Intel® Memory Protection Extensions (Intel® MPX)
Yes
Directed I/O virtualization (VT-d)
Yes
On-board graphics card maximum resolution (DisplayPort)
4096 x 2304
Commodity Classification Automated Tracking System (CCATS)
G077159
Intel® Hyper Threading Technology (Intel® HT Technology)
Yes
On-board graphics card refresh rate at maximum resolution (HDMI)
24
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)
4096 x 2304
On-board graphics card refresh rate at maximum resolution (DisplayPort)
60
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)
60
Powered by Icecat

Market Value History

Price history not started yet

Daily price tracking begins as soon as this product is listed on Amazon US — the trend chart will appear here automatically.

Sources

Brochure DELL 338-BUJC Icecat product datasheet

Product lifecycle

In production

Still listed as on-market by the manufacturer — actively sold and supported.

Lifecycle status is derived from catalog data and is indicative, not a manufacturer support guarantee.
