DELL logo MPN: 338-CLVY

DELL Intel Xeon Gold 5416S processor 2 GHz 30 MB Tray

Released: Not on record
Price not yet available US · Amazon.com

We track this product’s Amazon US price daily — it appears here as soon as it’s listed.

Cores
16
Threads
32
Base clock
2 GHz
Boost clock
4 GHz
Socket
LGA 4677 (Socket E)
TDP
150 W
Processor line
Intel Xeon Gold
Cache
30 MB
ECC support
Y
View 80 specifications
Shopping actions
Check price on Amazon

Overview

The Intel Xeon® Gold 5416S 2GHz Sixteen Core Processor enhances the performance and the speed of your system. Additionally, the Virtualization Technology enables migration of more environments. It supports enhanced SpeedStep® technology that allows tradeoffs to be made between performance and power consumption.

Its Thermal Monitoring Technologies protect the processor package and the system from thermal failure through several thermal management features. The VT-x with Extended Page Tables (EPT) also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Packed with more features, the Xeon Gold 5416S 2GHz Sixteen Core Processor is the ideal choice for virtually all of your data demanding or standard enterprise infrastructure applications.

Technical Specifications

Processor

12 SPECS
Stepping
S3
Cache
30 MB
Cores
16
Model
5416S
Processor line
Intel Xeon Gold
Socket
LGA 4677 (Socket E)
Threads
32
CPU brand
Intel
Base clock
2 GHz
Boost clock
4 GHz
CPU operating modes
64-bit
TDP
150 W

Memory

2 SPECS
ECC support
Yes
Max memory
4000 GB

General

66 SPECS
Max case temperature (Tcase)
79 °C
Status
Launched
DTS Max
90
64-bit support
Yes
Launch date
Q1'23
Scalability
2S
Packaging type
Tray
Market segment
Server
Use conditions
Server/Enterprise
Memory channels
Octa-channel
Package carrier
E1B
Bus speed
16 GT/s
Intel® OS Guard
Yes
Intel ARK ID
232396
Intel® Boot Guard
Yes
Low priority cores
12
Memory speed (max)
4400
Codename
Sapphire Rapids
Execute Disable (NX)
Yes
High priority cores
4
Number of UPI links
3
Generation
Intel Xeon Scalable 4th Gen
Dedicated graphics
No
Integrated graphics
No
PCI Express slots version
5.0
Long-term availability
No
Instruction sets
AMX,SSE4.2,AVX,AVX 2.0,AVX-512
Intel® Crypto Acceleration
Yes
Intel® Run Sure Technology
Yes
Low priority core frequency
1.7
Dedicated GPU model
Not available
High priority core frequency
2.1
Integrated GPU model
Not available
Intel® Speed Shift Technology
Yes
Intel® Turbo Boost Technology
2.0
Intel® Total Memory Encryption
Yes
Mode-based Execute Control (MBE)
Yes
Trusted Execution (TXT)
Yes
Intel® Dynamic Load Balancer (DLB)
2 default devices
PCIe lanes
80
Memory types supported by processor
DDR5-SDRAM
Intel® On Demand Feature Activation
Yes
Intel® QuickAssist Technology (QAT)
2 default devices
AVX-512 Fused Multiply-Add (FMA) units
2
Virtualization (VT-x)
Yes
Intel® Advanced Matrix Extensions (AMX)
Yes
Intel® Data Streaming Accelerator (DSA)
1 default devices
Intel® QuickAssist Software Acceleration
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
Memory clock speeds supported by processor
4400
Export Control Classification Number (ECCN)
5A992C
Intel Software Guard Extensions (Intel SGX)
Yes
Intel® Platform Firmware Resilience Support
Yes
Maximum Enclave Size Support for Intel® SGX
128
Intel® AES New Instructions (Intel® AES-NI)
Yes
Maximum internal memory supported by processor
4000
Intel® Optane™ DC Persistent Memory Supported
Yes
Intel® Transactional Synchronization Extensions
Yes
Intel® Control-flow Enforcement Technology (CET)
Yes
Intel® Resource Director Technology (Intel® RDT)
Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Yes
Directed I/O virtualization (VT-d)
Yes
Commodity Classification Automated Tracking System (CCATS)
G180729
Intel® Hyper Threading Technology (Intel® HT Technology)
Yes
Intel® Speed Select Technology - Base Frequency (Intel® SST-BF)
Yes
Intel® Speed Select technology - Performance Profile (Intel® SST-PP)
Yes
Powered by Icecat

Market Value History

Sources

Brochure DELL 338-CLVY Icecat product datasheet

Product lifecycle

In production

Still listed as on-market by the manufacturer — actively sold and supported.

Lifecycle status is derived from catalog data and is indicative, not a manufacturer support guarantee.
